Запчасти Case IH 2577 (90.108.06[02]) - DECALS - INFORMATION DECALS WITH READ OPERATORS MANUAL SYMBOL (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

319422A1

DECAL

Upper Relay, English

1шт.

1

319423A1

DECAL

Upper Relay, French

1шт.

1

319424A1

DECAL

Upper Relay, Spanish

1шт.

1

319426A1

DECAL

Upper Relay, Portuguese/Brazil

1шт.

1

319425A1

DECAL

Upper Relay, Europe/Russian

1шт.

2

392896A1

DECAL

Lower Fuse and Relay, English, Use with 388671A3, (Not Shown)

1шт.

2

392897A1

DECAL

Lower Fuse and Relay, French, Use with 388671A3, (Not Shown)

1шт.

2

392901A1

DECAL

Lower Fuse and Relay, Spanish, Use with 388671A3, (Not Shown)

1шт.

2

392899A1

DECAL

Lower Fuse and Relay, Portuguese/Brazil, Use with 388671A3, (Not Shown)

1шт.

2

392898A1

DECAL

Lower Fuse and Relay, Europe/Russian, (Not Shown)

1шт.

3

181992A1

DECAL

Without Power Guide Axle System

2шт.

4

181917A2

DECAL

With Power Guide Axle System

2шт.

5

401533A1

DECAL

Hydraulic Oil Level

1шт.

6

179620A2

DECAL

Lubrication Chart, LH

1шт.

7

435797A1

DECAL

Lubrication Chart, RH

1шт.

8

435798A1

DECAL

Lubrication Chart, Upper

1шт.

9

435799A1

DECAL

Inclined Delivery Auger Elevator

1шт.
