Артикул
Название
Примечание
Количество
1
1319908C1
SIDE PLATE
RH, Serial Range: -HAJ303001
1шт.
1
87675650
SIDE PLATE
RH, Start Serial: HAJ303001
1шт.
1a
251458A1
SIDE PLATE
RH, Extended Wear
1шт.
2
256873
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
1шт.
3
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
1шт.
4
1319901C1
SIDE PLATE
LH, Serial Range: -HAJ303001
1шт.
4
87675649
SIDE PLATE
LH, Start Serial: HAJ303001
1шт.
4a
282600A1
SIDE PLATE
LH, Extended Wear
1шт.
5
87301284
PLATE
Head Sealing
1шт.
6
1319940C1
COVER
Rear
1шт.
6a
251459A1
COVER
Rear, Extended Wear
1шт.
7
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
1шт.
8
231-4116
NUT,3/8"-16, GB
3шт.
9
198581A2
STIFFENER
Anchor Assy
1шт.
10
1317474C2
CHANNEL
1шт.
11
198602A1
COVER
Front
1шт.
Without Yield Monitor
1шт.
Without Advanced Farming System
1шт.
11
238646A1
COVER
Front
1шт.
With Yield Monitor
1шт.
With Advanced Farming System
1шт.
11a
251464A1
COVER
Front, Extended Wear
1шт.
With Yield Monitor
1шт.
With Advanced Farming System
1шт.
12
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
8шт.
14
820430C1
BOLT,Hex, 1/2" - 13 x 5 1/2", Full Thd
1/2" x 5-1/2"
2шт.
15
1317251C3
SUPPORT
2шт.
16
1310040C1
BAR
4шт.
17
87431216
COLLAR,31.77mm ID x 44.45mm OD x 15.9mm W
With Set Screw
2шт.
18
1317250C91
FLANGED BEARING,31.75mm ID
If Used, Optional with 65 - 67
2шт.
19
231-5146
FLANGE NUT,3/8"-16
4шт.
20
87515819
SHAFT
1шт.
21
495-81202
WASHER,1 9/32" x 1 3/4" x .060"
4шт.
22
126-125
WOODRUFF KEY,#B, 5/16" x 1", HT
2шт.
24
1317471C1
SPACER
2шт.
25
1318476C1
PLATE
1шт.
25a
251468A1
COVER
Extended Wear
1шт.
27
1321553C1
BRACKET
1шт.
28
1321833C1
STRAP
1шт.
29
121370A1
PLATE
LH Front
1шт.
29a
334204A1
PLATE
LH Front, Extended Wear
1шт.
33
1321550C2
SUPPORT
Rear
1шт.
33a
298841A1
SHEET
Rear, Extended Wear
1шт.
34
1319954C1
BRACKET
1шт.
34a
251470A1
BRACKET
Extended Wear
1шт.
35
413-5144
BOLT,Hex, 5/16" - 18 x 9", Gr 5
1шт.
37
425-105
NUT,5/16"-18, G5
1шт.
40
1321095C1
PANEL
RH
1шт.
41
409-7516
BOLT,Hex Flg, 5/16" - 18 x 1", Spcl
5шт.
42
1321097C2
COVER
1шт.
44
1321060C1
SUPPORT
1шт.
45
1321497C1
PANEL
LH
1шт.
46
1321155C1
SPACER
1шт.
47
1321263C1
RUBBER SEAL,1137mm L
2шт.
48
1321554C1
PLATE
1шт.
50
1321556C1
COVER
1шт.
51
256873
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
1шт.
52
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
1шт.
53
199006A2
TUBE,887 mm Length
Lower
1шт.
53a
251472A1
GUARD
Lower, Extended Wear
1шт.
55
1321560C3
TUBE
Upper
1шт.
56
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
4шт.
56
409-7520
BOLT,Hex Flg, 5/16" - 18 x 1 1/4", Spcl
4шт.
57
1321568C3
ANGLE
Front
1шт.
57a
297934A1
SUPPORT
Front, Extended Wear
1шт.
58
1321569C3
ANGLE
Rear
1шт.
58a
297936A1
SUPPORT
Rear, Extended Wear
1шт.
60
1979134C1
SUPPORT
1шт.
60a
249274A1
SUPPORT
Extended Wear
1шт.
61
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
, Serial Range: -HAJ303001
4шт.
61
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
, Start Serial: HAJ303001
4шт.
64
1321552C2
SUPPORT
Front
1шт.
64a
253270A1
GUARD
Front, Extended Wear
1шт.
65
156010C92
BALL BEARING,31.75mm ID x 62mm OD x 18mm W
If Used, Optional with Ref 18
2шт.
66
87106572
FLANGE
Used with Ref 65, 67
4шт.
67
1979642C1
SPACER
Used with Ref 65, 66
2шт.
68
229609A2
COWL
Front, Corn And Grain
1шт.
69
325494A1
HOOD
Extended Wear
1шт.
71
353-147
PLUG
Sleeve (Not Shown)
1шт.
72
410009A1
SPRING NUT
Self-Retaining
6шт.
Выбрано товаров: 83
