Запчасти Case IH 2577 (44.151.11) - AXLE ASSY - DRIVE, WITHOUT EXTENSIONS (44) - WHEELS

1

87526461

AXLE

, Serial Range: -HAJ301909

1шт.

1

87617568

AXLE

, Start Serial: HAJ301909

1шт.

2

135314A1

BUSHING,20.1mm ID x 21.75mm OD x 12.7mm L

4шт.

3

87335705

SILL

Support, RH Shown

1шт.

4

426-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 8

1шт.

4

426-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 8

1шт.

4

426-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 8

1шт.

5

627-20060

BOLT,Hex, M20 x 2.5 x 60mm, Cl 10.9, Full Thd

1шт.

6

87301493

SERRATED NUT,Flg, USR, 5/8"-11, G8

1шт.

7

87386289

POST

Separator, RH Shown

1шт.

8

326-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 8

1шт.

9

496-41066

WASHER,5/8" ID x 1-1/2" OD x 3/16" Thk

If Used

1шт.

10

496-11066

WASHER,21/32" x 1 5/16" x .095", HDN

1шт.

11

87527680

PLATE

Reinforcement

2шт.
