Артикул
Название
Примечание
Количество
1
86991459
RESERVOIR, HYDRAULIC
1шт.
2
1541688C1
FLEXIBLE HOSE
660 mm (26"), Suction to Reel Drive Pump, Cut from 1541953C1
1шт.
3
214-3232
HOSE CLAMP,1-1/4" - 2-1/8", HD Worm, W/ Liner
2шт.
4
217-317
FITTING,45 Degree Elbow, 1-1/4" Hose Barb x 1-5/8" - 12 Male ORB
Incl 5
1шт.
5
237-6020
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
1шт.
6
184618A1
FLEXIBLE HOSE
305 mm (12-1/8"), Suction to Header Lift Pump, Cut from 1541953C1
1шт.
7
214-3232
HOSE CLAMP,1-1/4" - 2-1/8", HD Worm, W/ Liner
2шт.
8
182811A1
ELBOW
Incl 9
1шт.
9
237-6020
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
1шт.
10
NSS
NOT SOLD SEPARAT
PUMP, HYDRAULIC, Auxiliary
1шт.
Order Component Parts
1шт.
11
217-178
FITTING,1-1/4" Hose Barb x 1-5/8" - 12 Male ORB
1шт.
13
182813A1
TEE
1-1/4" x 1" x 1", Incl 14
1шт.
14
237-6020
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
1шт.
15
217-387
FITTING,3/8" Hose Barb x 9/16" - 18 Male ORB
Incl 16
1шт.
16
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
17
128005A1
HYDRAULIC HOSE,9.52 mm ID x 445.00 mm
Pump Case Drain, Cut from S118400X
1шт.
18
214-1706
HOSE CLAMP,#06, 0.44" - 0.78", Type M Worm
2шт.
19
217-347
FITTING,90 Degree Elbow, 3/8" Hose Barb x 9/16" - 18 Male ORB
Incl 20
1шт.
20
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
21
201-100
HYD CONNECTOR,9/16" - 18 Male ORFS x 7/16" - 20 Male ORB
Incl 22, 23
1шт.
22
237-6004
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
23
238-6011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
1шт.
24
201-434
TEE,11/16"-18 ORFS x 11/16"-18 Sw Br
Incl 25
1шт.
25
238-6012
O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro
2шт.
27
236558A1
CLAMP
2шт.
28
413-420
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
2шт.
29
231-5344
FLANGE NUT,Flg, 1/4"-20
2шт.
30
238-6011
O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro
1шт.
31
255209A1
FLEXIBLE HOSE
530 mm (20-7/8"), Pump Signal
1шт.
31a
201-145
REDUCER,9/16"-18 Male x 11/16"-16 Fem, ORFS
(Not Shown)
1шт.
32
114851A2
VALVE
Steering
1шт.
34
252596A1
TUBE,0.375" OD, 2106.5 mm Length
Signal
1шт.
36
255212A1
CLAMP
1шт.
37
413-420
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
1шт.
39
384307A1
SOLENOID VALVE
Pressure Regulator
1шт.
40
201-306
90 ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x 7/8" - 14 Male ORB
Incl 41, 42
1шт.
41
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
42
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
43
201-307
ELBOW,90 Degree Elbow, 1-3/16" - 12 Male ORFS x 1-1/16" - 12 Male ORB
Incl 44, 45
1шт.
44
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
45
238-6018
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
1шт.
46
201-112
HYD CONNECTOR,13/16" - 16 Male ORFS x 7/8" - 14 Male ORB
1шт.
48
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
Выбрано товаров: 46
