Запчасти Case IH 2388 (09B-13[01]) - KIT EXTENDED WEAR TRAN CONE VANES (14) - ROTOR, CONCANVES & SIEVE

1

84272906

SERVICE KIT

Incl 2 - 10

1шт.

2

6-17011

OPERATOR MANUAL

1шт.

3

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

58шт.

4

87547587

LOCK NUT,Hex, M10 x 1.5, Cl 10

58шт.

5

87106338

BOLT

58шт.

6

347918A1

STIFFENER

LEFT POCKET

1шт.

7

347913A1

VANE

TOP CONE RING

1шт.

8

418655A2

STIFFENER

SHORT TRANSPORT

1шт.

9

418654A2

VANE

FRONT TRANSPORT

4шт.

10

411518A2

VANE

CAGE TRANSPORT

2шт.
