Артикул
Название
Примечание
Количество
1
87300716
MOTOR, HYDRAULIC
Wheel Drive
2шт.
Corn and Grain Combine
1шт.
See Figure 05-14
1шт.
87300716R
REMAN-HYDROSTAT MOTO
2388 - CASE IH AXIAL-FLOW COMBINE BTW HAJ292001 & HAJ300000 - 10/04,
2шт.
87300716C
CORE-HYDROSTAT MOTOR
Return Number
1шт.
2
1970138C1
HOUSING
King Pin
2шт.
3
406799A1
FRAME
RH, Incl. (2) 1970142C1, Ref 7
1шт.
Corn and Grain Combine
1шт.
3
1970354C1
FRAME
LH, Incl. (2) 1970142C1, Ref 7
1шт.
Corn and Grain Combine
1шт.
3
431231A1
FRAME
RH, Incl. (2) 1970142C1, Ref 7
1шт.
Rice Combine
1шт.
3
1347196C1
FRAME
LH, Incl. (2) 1970142C1, Ref 7
1шт.
Rice Combine
1шт.
5
41-3040
PLUG,Exp, 2 1/2"
4шт.
6
219-57
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
4шт.
7
1970142C1
BUSHING
4шт.
8
1970143C1
PIN,47.63mm OD x 231.78mm L
King
2шт.
10
1970381C1
THRUST WASHER
Steel
1-2шт.
11
1970382C1
THRUST WASHER
Bronze
4шт.
12
83-15020
SET SCREW,Hex Soc, 1/2"-13 x 1 1/4"
2шт.
13
1970148C1
CLAMP
8шт.
Corn and Grain Combine
1шт.
14
1970150C1
PLATE
2шт.
Corn and Grain Combine
1шт.
15
326-532
BOLT,Hex, 5/16" - 18 x 2", Gr 8
4шт.
19
1970146C1
HYD TUBE
Pressure, RH Rear, LH Front
2шт.
Corn and Grain Combine
1шт.
20
1970147C1
HYD TUBE
Pressure, LH Rear, RH Front
2шт.
Corn and Grain Combine
1шт.
21
496-21066
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
20шт.
Corn and Grain Combine
1шт.
92 - 120" Power Guide Axle
1шт.
22
426-1024
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 8
20шт.
Corn and Grain Combine
1шт.
92 - 120" Power Guide Axle
1шт.
23
1970151C1
STUD
Included with Ref. 1
16шт.
24
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
Incl. 25
2шт.
25
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
26
218-5064
HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB
Incl. 27
4шт.
27
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
28
326-1236
BOLT,Hex, 3/4" - 10 x 2-1/4", Gr 8
12шт.
29
496-21081
WASHER,13/16" x 1 1/2" x .179", HDN
12шт.
30
326-1028
BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 8
4шт.
31
329-1410
JAM NUT,Jam, 5/8"-11, G8
4шт.
35
1970153C3
WHEEL ASSY
26 x 16, For 16.9 x 26" Tire, For 18.4 x 26" Tire, 8 Hole Pattern
2шт.
Corn and Grain Combine
1шт.
35
360213A1
WHEEL ASSY.
26 x 15, For 18.4 x 26" Tire, 10 Hole Pattern
2шт.
35
257875A2
WHEEL ASSY
28 x 18, For 600/65-R28" Tire, 8 Hole Pattern
2шт.
Corn and Grain Combine
1шт.
35
257878A2
WHEEL ASSY
28 x 18 For 600/65-R28" Tire, 10 Hole Pattern
2шт.
35
220201A1
WHEEL ASSY
30 x 16 For 18.4 x 30" Tire, 10 Hole Pattern
2шт.
36
1541701C1
FLANGE NUT
1шт.
37
179482C1
VALVE STEM
Tire, Not Illustrated
2шт.
38
407184C1
VALVE STEM
Core, Tire, Not Illustrated
2шт.
39
359846A1
PLUG
Tire Valve Hole, Not Illustrated
2шт.
40
181917A2
DECAL
Wheel Bolt Torque
2шт.
See Figure 09H-20
1шт.
Выбрано товаров: 60
