Запчасти Case IH 2388 (09H-03) - SEPARATOR - DOORS - LEFT HAND (12) - CHASSIS

1

1989327C2

RETAINER

1шт.

1

1989327C3

RETAINER

12 Row Ready

1шт.

2

418694A1

ROD,25.4mm OD

1шт.

3

1978738C1

HAIR PIN COTTER

3/16"

1шт.

4

139620A5

POST

LH Front, Includes Decal, See Figure(s) 09H-23, Ref. 9, Serial Range: -JJC0268799

1шт.

4

393184A1

POST

LH Front, Includes Decal, See Figure(s) 09H-23, Ref. 9, Start Serial: JJC0268800

1шт.

4a

120253C1

CONDUIT

210 mm (8-1/4"), Cut from 1262114C1, Not Illustrated

1шт.

5

320800A3

SIDE PLATE

LH, Replaces 1968985C9, Serial Range: -JJC0268799

1шт.

5

356866A2

SIDE PLATE

LH, Serial Range: JJC0268800-JJC0272999

1шт.

5

443249A1

FRAME

LH, Start Serial: JJC0273000

1шт.

6

193223C2

DOOR

LH Front

1шт.

7

160638C2

HANDLE

Replaces 160638C1

2шт.

8

193353C1

DOOR

LH

1шт.

9

167800C1

CLIP

10шт.

10

1327695C8

SUPPORT

Main, LH, Serial Range: -JJC0268799

1шт.

10

359826A2

SILL

Main, LH, Start Serial: JJC0268800

1шт.

12

188062C2

DOOR SEAL,12.7mm H x 25.4mm W x 140mm L

140 mm (5-1/2"), Cut from 1338148CX

1шт.

13

237975A5

SUPPORT

1шт.

14

186018C1

STRAP

1шт.

15

426-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 8

20шт.

15

426-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 8

3шт.

16

181085C4

DOOR

Side, Serial Range: -JJC0275338

1шт.

16a

87301105

DOOR

, Start Serial: JJC0275339

1шт.

17

232-51310

FLANGE NUT,Flg, USR, 5/8"-12

24шт.

18

426-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 8

21шт.

19

496-21053

WASHER,17/32" x 1 1/16" x .134"

39шт.

20

186852C1

FLANGE NUT,Hex, 1/2"-13, Lock

1/2", 8

3шт.

21

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

4шт.

22

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

9шт.

23

440-1108

SCREW,Cross Pan Hd, #10-24 x 1/2"

10шт.

24

231-51409

SERRATED NUT,Flg, USR, #10-24

10шт.

25

396-41066

WASHER,16.66mm ID x 38.1mm OD x 5.05mm Thk

6шт.

26

496-11066

WASHER,21/32" x 1 5/16" x .095", HDN

13шт.

27

426-816

BOLT,Hex, 1/2" - 13 x 1", Gr 8

11шт.

28

232-5138

FLANGE NUT,Flg, USR, 1/2"-13, G8

12шт.

29

413-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5

2шт.

30

492-11062

BEARING WASHER,5/8"

2шт.

31

425-1010

NUT,5/8"-11, G5

2шт.

33

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

8шт.

33

477-73116

SERRATED SCREW,Truss HD, 5/16" - 18 x 1"

1шт.

33

409-7524

BOLT,Hex Flg, 5/16" - 18 x 1 1/2", Spcl

4шт.

34

231-5146

FLANGE NUT,3/8"-16

9шт.

34

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

4шт.

35

477-73812

SERRATED SCREW,Truss HD, 3/8" - 16 x 3/4"

20шт.

35

477-73816

SERRATED SCREW,Sl Truss Hd, 3/8" x 1"

2шт.

36

493-21065

LOCK WASHER,Int Tooth, 5/8"

2шт.

37

188062C2

DOOR SEAL,12.7mm H x 25.4mm W x 140mm L

140 mm (5-1/2"), Cut from 1338149C1, Not Illustrated

4шт.

38

198572A1

STRAP

12 Row Ready, Serial Range: -JJC0270499

1шт.

Rice Combine

1шт.

38

198572A3

STRAP

12 Row Ready, Start Serial: JJC0270500

2шт.

Rice Combine

1шт.

39

426-632

BOLT,Hex, 3/8" - 16 x 2", Gr 8

12 Row Ready

2шт.

Rice Combine

1шт.

40

496-41041

WASHER,13/32" x 1 1/8" x .134"

4шт.

Rice Combine

1шт.

41

429-106

NUT,3/8"-16, G8

12 Row Ready

4шт.

Rice Combine

1шт.

42

426-832

BOLT,Hex, 1/2" - 13 x 2", Gr 8

14шт.

Rice Combine

1шт.

43

496-21053

WASHER,17/32" x 1 1/16" x .134"

28шт.

Rice Combine

1шт.

44

429-108

NUT,1/2"-13, G8

14шт.

Rice Combine

1шт.

45

236933A1

PLATE

1шт.

46

238987A1

PLATE

LH Front

1шт.

47

239001A1

PLATE

1шт.

48

236509A1

SPACER

2шт.

49

239289A1

SPACER

Lower RH

1шт.

50

236370A2

PLATE

LH

1шт.

51

236726A1

PLATE

LH

1шт.

387815A1

DOOR

Separator, Includes Ref. 52 - 56, Start Serial: JJC0268800

1шт.

52

383558A1

DOOR

, Start Serial: JJC0268800

1шт.

53

397586A1

HINGE

, Start Serial: JJC0268800

1шт.

54

477-82508

SERRATED SCREW,Sl Truss Hd, 1/4" - 20 x 1/2"

2шт.

55

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

2шт.

56

383559A1

SEAL

1шт.

57

167800C1

CLIP

1шт.

58

440-1108

SCREW,Cross Pan Hd, #10-24 x 1/2"

1шт.

59

231-51409

SERRATED NUT,Flg, USR, #10-24

1шт.

60

477-82508

SERRATED SCREW,Sl Truss Hd, 1/4" - 20 x 1/2"

2шт.

61

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

2шт.

62

329-288

FLANGE NUT,Flg, 1/2"-13, G8

6шт.

63

409-7620

BOLT,Hex Flg, 3/8" - 16 x 1 1/4", Spcl

2шт.

64

426-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 8

1шт.

65

193816C2

SUPPORT

Support, Shaker Shaft and Auger Drive, Weld

1шт.

426155A1

KIT

Sieve Light / Viewing Door, Includes 23, 24, 34, 52, 54 - 56, 60 - 61. Also Includes 1347069C1. See Figure 04-6, 09H-03, 09H-25, 09H-26

1шт.

Use to retrofit machines built prior to P.I.N. JJC0270499.

1шт.
