Запчасти Case IH 2377 (09A-18[01]) - KIT 3 STRAND SMOOTH 54.5 W/O DRUM (13) - FEEDER

1

B93532

PACKAGE

Incl 2 - 12

1шт.

2

8-97672

MANUAL, OPERATORS

1шт.

3

185817C3

PLATE

1шт.

4

84207190

CHAIN,Feeder, 69 Links x 41.4mm = 2857.5mm

1шт.

5

87530580

STRIPPER

1шт.

6

1989592C1

SUPPORT

LH

1шт.

7

1989593C1

SUPPORT

RH

1шт.

8

247780

SERRATED NUT,Flg, USR, 3/8"-16

6шт.

9

233211A1

SHEET

1шт.

10

86624124

SERRATED SCREW,Truss HD, 3/8" - 16 x 3/4"

6шт.

11

87613203

WASHER,1.78" ID x 2.5" OD x 0.06" Thk

6шт.

12

87315913

SPROCKET ASSY.,Feeder

1шт.
