Запчасти Case IH 2344 (03-07[01]) - FUEL, RETURN - ASN JJC0255000 (02) - FUEL SYSTEM

Схема запчастей Case IH 2344 - (03-07[01]) - FUEL, RETURN - ASN JJC0255000 (02) - FUEL SYSTEM
13
10
8
22
14
12
17
22
9
20
3
11
18
5
6
15
11
4
16
10
8
4
9
4
21
22
11
4
7

Артикул

Название

Примечание

Количество

3

385579A1

HOSE

152 mm (6 in), Cut From S118400

1шт.

4

214-1406

HOSE CLAMP,#06, 0.44" - 0.78", Type F Worm

5шт.

5

REF

INSTRUCTION

Cooler, Oil, See Figure(s) 08-05, 08-06

1шт.

6

384824A1

FUEL TUBE,0.375" OD, 423.6, 312.4 mm Length

1шт.

7

409390A2

BRACKET

Support

1шт.

9

495-81121

WASHER,.344" x 1 1/2" x .060"

11/32 x 1-1/2 x 1/16

4шт.

10

231-5344

FLANGE NUT,Flg, 1/4"-20

4шт.

11

236558A1

CLAMP

3шт.

12

198824C1

GROMMET,12.7mm ID x 41.1mm OD x 26.9mm Thk

1/2" ID

2шт.

13

178950C2

ANGLE

1шт.

14

193624A2

FUEL HOSE,9.53 mm ID x 770.00 mm, SAE 30R2

1шт.

15

515-2595

CLAMP,3/8", Insul, 1/2" Bolt

2шт.

16

198828C1

GROMMET,25.4mm ID x 41.1mm OD x 26.9mm Thk

1шт.

17

1977005C1

SUPPORT

1шт.

18

413079A1

FUEL HOSE,12.70 mm ID x 198.00 mm, SAE 30R2

Cut From S118400

1шт.

20

390576A1

FUEL TUBE

Fuel Return

1шт.

21

364783A1

TUBE

1750 mm (68-7/8 in)

1шт.

22

1348264C1

HOSE CLAMP

3/8 ID

2шт.

8

413-420

BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5

3шт.

Выбрано товаров: 19
