Артикул
Название
Примечание
Количество
A77704
PUMP, WATER
KIT - water pump, Inlcudes: Ref. 1 - 3
1шт.
J800976R
REMAN-WATER PUMP
2188 6TA-830 EMISSIONS CERTIFIED ENGINE COMBINE P.I.N. JJC0191483 (1/95-12/97), Reman for New P/N A77704
1шт.
J800976C
CORE-WATER PUMP
Return Number
1шт.
1
NSS
NOT SOLD SEPARAT
PUMP - water, new, order kit A77704
1шт.
2
NSS
NOT SOLD SEPARAT
PULLEY - water pump, order kit A77704
1шт.
3
J902089
SEAL,0.139" Thk x 3.859" ID, -241
O-RING - sealing
1шт.
4
J926125
BOLT,Hex, M8 x 28mm, Cl 8.8
BOLT - hex, special, 8 - 1.25 x 28 mm
3шт.
5
J929458
SUPPORT
ASSEMBLY - fan, Inlcudes: Ref. 6 - 10
1шт.
6
J907769
BOLT,Hex, M10 x 70mm, Cl 12.9
- hex, special, 10 - 1.5 x 70 mm, class 12.9
1шт.
7
J923044
RETAINER
- fan hub
1шт.
8
100-21250
SNAP RING,2.50", Int, #250
Ring, Snap, 2.50", Int, #250
2шт.
9
J910739
BALL BEARING,35mm ID x 64mm OD x 37mm W
BEARING - ball
1шт.
10
J911924
HUB
- fan
1шт.
11
845-8050
BOLT,Hvy Hex, M8 x 50mm, Cl 8.8
- heavy hex flange, 8 - 1.25 x 50 mm, fan support to cylinder head
4шт.
13
J925211
BRACKET
- mounting, tensioner
1шт.
14
845-8025
BOLT,Hex Flg, M8 x 25mm, Cl 8.8
- heavy hex flange, 8 - 1.25 x 25 mm
2шт.
16
854-10075
BOLT,Hvy Hex, M10 x 75mm, Cl 10.9
- heavy hex flange, 10 - 1.5 x 75 mm, class 10.9, belt tensioner to mounting bracket
1шт.
17
J911572
V-BELT,27.92mm W x 1549.4mm L, 8 Ribs
Fan Drive 3.56 mm W x 1549.90 mm L, 8 Ribs
1шт.
18
A184548
SPACER,Fan, 89/90mm Thk
- fan, 90 mm long
1шт.
19
237157A1
FAN
- engine, puller (Replaces fans 1547933C1 and 117036A1)
1шт.
20
814-10125
BOLT,Hex, M10 x 1.5 x 125mm, Cl 8.8
- hex, 10 - 1.5 x 130 mm, used with 1547933C1 and 117036A1 fans (Replaces 814-10130)
4шт.
20
814-10125
BOLT,Hex, M10 x 1.5 x 125mm, Cl 8.8
- hex, 10 - 1.5 x 125 mm, used with 237157A1 fan
4шт.
22
96-81004
WASHER,0.41" ID x 1.25" OD x 0.24" Thk
- flat, 13/32 x 1-1/4 x 15/64 inch, hardened, if used, not shown
4шт.
23
A77817
KIT
KIT - belt tensioner pulley, used to replace pulley of J918944 belt tensioner, Ref. 15, Inlcudes: Ref. 24 - 26
1шт.
24
NSS
NOT SOLD SEPARAT
PULLEY - belt tensioner, order kit A77817
1шт.
25
NSS
NOT SOLD SEPARAT
BOLT - pulley, order kit A77817
1шт.
26
NSS
NOT SOLD SEPARAT
SEAL - bolt, order kit A77817
1шт.
Выбрано товаров: 30
