Запчасти Case IH 2188 (6-60) - DRIVE AXLE (03) - POWER TRAIN

1

136416A4

AXLE

- drive, use on combines with dual wheels

1шт.

1

136417A3

AXLE

- drive, use on combines with track attachment

1шт.

For use with combines equipped with track attachment.

1шт.

2

135314A1

BUSHING,20.1mm ID x 21.75mm OD x 12.7mm L

- tapered

4шт.

3

REF

INSTRUCTION

SUPPORT - separator side, right-hand shown, see Ref. 10 (left-hand), Figure 9H-6 and Ref. 9 (right-hand), Figure 9H-8

1шт.

4

426-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 8

- hex, 5/8 NC x 1-1/4 inch, grade 8

1шт.

5

137339A2

WASHER,21mm ID x 33.5mm OD x 4mm Thk

- flat, special, 22 x 34 x 3.4 mm

1шт.

6

232-51310

FLANGE NUT,Flg, USR, 5/8"-12

- hex serrated flange, 5/8 inch NC, grade 8

1шт.

7

REF

INSTRUCTION

POST - separator front, right-hand shown, see Ref. 4 (left-hand), Figure 9H-6 and Ref. 7 (right-hand), Figure 9H-8

1шт.

8

326-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 8

1шт.

9

396-41066

WASHER,16.66mm ID x 38.1mm OD x 5.05mm Thk

- flat, 21/32 x 1-1/2 x 3/16 inch, hardened

1шт.

10

169256C2

WASHER,16.28mm ID x 31.8mm OD x 3.05mm Thk

- flat, special, 41/64 x 1-1/2 x 1/8 inch

1шт.

11

186832C2

PLATE

- outer pivot support

2шт.

For use with combines equipped with track attachment.

1шт.

12

827-20070

BOLT,Hex, M20 x 2.5 x 70mm, Cl 10.9

- hex, 20 - 2.5 x 70 mm, class 10.9

14шт.

For use with combines equipped with track attachment.

1шт.

14

137339A2

WASHER,21mm ID x 33.5mm OD x 4mm Thk

- flat, special, 22 x 34 x 3.4 mm

14шт.

For use with combines equipped with track attachment.

1шт.

15

1338130C1

SHIELD

- axle shaft

2шт.

For use with combines equipped with track attachment.

1шт.

16

413-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

4шт.

For use with combines equipped with track attachment.

1шт.

17

231-5146

FLANGE NUT,3/8"-16

4шт.

For use with combines equipped with track attachment.

1шт.

18

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

(Flat, 13/32 x 13/16 x 1/16") 3/8", SAE

4шт.

For use with combines equipped with track attachment.

1шт.

19

186016C4

SUPPORT

Bracket, LH shield

1шт.

For use with combines equipped with track attachment.

1шт.

20

186017C4

SUPPORT

Bracket - Support, RH shield

1шт.

For use with combines equipped with track attachment.

1шт.

21

614-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8

6шт.

For use with combines equipped with track attachment.

1шт.

22

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

- flat, 11 x 21 x 2 mm

6шт.

For use with combines equipped with track attachment.

1шт.

23

135705A1

SHAFT

- axle, 770 mm, drive, Serial Range: -JJC0193725

2шт.

For use with combines equipped with track attachment.

1шт.

23

242853A1

SHAFT

- axle, 770 mm, drive JJC0193725 to

2шт.

23

126099A2

SHAFT

- final drive, 748 mm, with no axle extensions, prior to combine P.I.N. JJC0193725

2шт.

23

242846A1

SHAFT

- final drive, 748 mm, with no axle extensions, after combine P.I.N. JJC0193725

2шт.

24

236510A1

PLATE

- reinforcement

2шт.

25

246457A1

LARGE PLATE

PLATE - axle end

2шт.

Is only available as a kit, including flange and instruction sheet. The part number for the kit is 245553A1.

1шт.
