Артикул
Название
Примечание
Количество
1
122744A5
BRACKET
- shift mounting
1шт.
2
825-5148
SERRATED NUT,M8, Flg Ser
4шт.
3
122751A3
LEVER
- transmission shift, 2nd and 3rd speed
1шт.
4
122205A3
HANDLE
KNOB - shift lever
1шт.
5
838-1428
LOCK PIN,M4 x 28, Slotted
PIN - roll, 4 x 28 mm
4шт.
6
S115001
FLANGED BEARING,0.502" ID x 0.627" OD x 0.3125"
BUSHING - shift lever bracket
2шт.
7
122199A1
PIVOT PIN,12.7mm OD x 73mm L
PIN - pivot
1шт.
197971A1
TUBE
ASSEMBLY - transmission shift, 1st speed, Includes: Ref. 8 and 9
1шт.
8
122754A3
TUBE
- transmission shift, 1st speed, order tube assembly
1шт.
9
90-4368T1
BUSHING,15.95mm ID x 19.13mm OD x 7.92mm L
- lever pivot
2шт.
10
125803A1
SLEEVE
COVER - vinyl, shift tube handle
1шт.
11
122197A2
SPLIT PIN/SAFETY PIN
PIN - shift tube, to 1st speed cable
1шт.
12
432-612
COTTER PIN,3/32" x 3/4"
PIN , SPLIT (COTTER), 3/32" x 3/4"
1шт.
13
115398A1
CABLE,3209mm L
- transmission shift, first speed
1шт.
14
124714A1
LARGE PLATE
LINK - shift lever
1шт.
15
122757A3
GUIDE
GATE - shift lever
1шт.
16
614-6020
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
- hex, full threads, 6 - 1.0 x 20 mm
4шт.
17
825-5146
SERRATED NUT,M6, Flg Ser
4шт.
18
427-6325
CLEVIS PIN,3/8" x 3 1/4"
PIN - clevis, 3/8 x 3-1/4 inch, hardened
1шт.
19
427-5094
CLEVIS PIN,7.92mm OD x 23.88mm L
PIN - clevis, 5/16 x 15/16 inch, hardened
1шт.
20
432-612
COTTER PIN,3/32" x 3/4"
PIN , SPLIT (COTTER), 3/32" x 3/4"
2шт.
21
840-1420
SCREW,Pan, M4 x 20mm, Cl 4.8
- machine, pan Phillips, 4 - 0.7 x 20 mm
2шт.
23
824-1404
NUT,M4, Cl 5
- hex, 4 mm - 0.7, class 5
2шт.
24
213-125
ADJUSTABLE CLEVIS,5/16" - 32
CLEVIS - adjustable, 5/16 inch NF
1шт.
25
115397A1
CABLE,3571mm L
- transmission shift, 2nd and 3rd speed
1шт.
26
122750A1
PLATE
- bulkhead at cab
1шт.
27
122758A1
GASKET
- bulkhead plate
1шт.
31
463-10412
SCREW,Hex Hd, #4-40 x 3/4"
- machine, hex head, No. 4 NC x 3/4 inch
2шт.
32
495-31012
WASHER,#4
- flat, 1/8 x 5/16 x 1/32 inch
2шт.
33
225-14104
NUT,#4-40
2шт.
28
281-53510
SELF-TAP SCREW,Hex Wash Hd, #10 x 5/8"
SCREW, SELF TAP, Hex Wash Hd, #10 x 5/8"
2шт.
Выбрано товаров: 33
