Артикул
Название
Примечание
Количество
1
115730A1
SHEET
SHIELD - grain tank access hole
1шт.
2
185668A1
SUPPORT
STRAP - guard, access hole
1шт.
3
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
- serrated slotted truss head, 5/16 NC x 3/4"
7шт.
4
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
7шт.
6
124001A1
SUPPORT
BRACKET - support, grain sampling, lower
1шт.
7
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
- serrated slotted truss head, 5/16 NC x 3/4"
2шт.
8
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
2шт.
9
126046A1
GASKET,287.02mm L
TRIM - edge, black, 11-1/2 inch (292 mm) long, cut from 1330108CX bulk trim below, sample hole bottom edge
1шт.
10
123977A2
BOTTOM
TROUGH - sampling, grain tank
1шт.
11
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
- serrated slotted truss head, 5/16 NC x 3/4"
2шт.
14
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
2шт.
15
124000A1
SUPPORT
BRACKET - support, grain sampling, upper, inclined delivery auger
1шт.
15a
134101A1
SUPPORT
BRACKET - support, grain sampling, upper, horizontal delivery auger, not shown
1шт.
16
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
2шт.
17
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
2шт.
18
120550A1
GLASS
- window, grain tank
1шт.
19
NSS
NOT SOLD SEPARAT
SEAL - 60 inch (1524 mm) long, cut from bulk seal 198131C2 below
1шт.
20
129073A1
HANDLE
HANDRAIL - grain delivery, upper step, inclined delivery auger
1шт.
21
129077A3
SUPPORT
BRACKET - angle, front step
2шт.
22
141410A1
SUPPORT
- step, front valve stack bracket
2шт.
23
1531337C1
STEP
- service
2шт.
24
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
16шт.
28
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
16шт.
29
129079A2
SUPPORT
BRACKET - angle, step support
1шт.
30
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
3шт.
31
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
3шт.
32
129080A2
LADDER
STEP - double
1шт.
33
275-14712
SELF-TAP SCREW,Hex Hd, 1/4" x 3/4"
SCREW - hex, self tapping, 1/4-14 x 3/4 inch
4шт.
34
185348A1
GRAB RAIL
HANDRAIL - grain delivery, upper step, horizontal delivery auger
1шт.
1330108CX
SEAL,304.8mm L
TRIM - edge, bulk, 600 inch (15240 mm) long
1шт.
198131C2
SEAL, GLASS
SEAL - bulk, 120 inch (3048 mm) long
1шт.
Выбрано товаров: 31
