Артикул
Название
Примечание
Количество
1
181921A4
AXLE
- drive, 76 inch, shown
1шт.
1a
238567A2
AXLE
- drive, 88 inch, not shown
1шт.
2
177336C1
COVER
- end plate, if used
2шт.
4
REF
INSTRUCTION
SUPPORT - separator side, right-hand, see item 14 (left-hand), Figure 9H-4 and item 11 (right-hand), Figure 9H-6
1шт.
5
426-1020
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 8
- hex, 5/8 NC x 1-1/4 inch, grade 8
22шт.
6
137339A2
WASHER,21mm ID x 33.5mm OD x 4mm Thk
- flat, special, 22 x 34 x 3.4 mm
14шт.
7
232-51310
FLANGE NUT,Flg, USR, 5/8"-12
- hex serrated flange, 5/8 inch NC, grade 8
30шт.
8
REF
INSTRUCTION
POST - separator front, right-hand, see item 4 (left-hand), Figure 9H-4 and item 6 (right-hand), Figure 9H-6
1шт.
9
326-1024
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 8
8шт.
10
396-41066
WASHER,16.66mm ID x 38.1mm OD x 5.05mm Thk
- flat, 21/32 x 1-1/2 x 3/16 inch, hardened
4шт.
11
WASHER,16.28mm ID x 31.8mm OD x 3.05mm Thk
- flat, special, 41/64 x 1-1/2 x 1/8 inch
12шт.
12
246457A1
LARGE PLATE
PLATE - axle end, if used
2шт.
Ref # 12 (246457A1): Do not order, per Elliot. This should not even be in this catalog!! SMA 9-18-97
1шт.
Выбрано товаров: 13
