Артикул
Название
Примечание
Количество
1
1308916C2
SHIELD
- side, straw spreader
2шт.
1a
103211A2
SHIELD
- side, straw and chaff spreader
2шт.
2
256873
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
1шт.
3
1308912C3
PIPE
- shield
2шт.
4
515-28175
CLAMP,17.5mm ID, 10.3mm Bolt Hole, P Type
- P-type, 11/16 inch ID
6шт.
5
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
9шт.
6
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
5шт.
7
183958A2
SUPPORT
- straw spreader, right-hand shield
1шт.
8
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
4шт.
9
231-4115
NUT,5/16"-18, GB
NUT - hex, self-locking, 5/16 inch NC
1шт.
10
WASHER,8.74mm ID x 25.4mm OD x 1.7mm Thk
- flat, 11/32 x 1 x 3/64 inch, used with item 1 only
8шт.
11
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
2шт.
12
237960A1
GUARD
SHIELD - straw spreader belt, includes decals, see pages 9H-37 and 9H-39 for decals (Replaces shield 193430A2)
1шт.
13
1308913C1
SUPPORT
- straw spreader shield
2шт.
14
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
BOLT - serrated slotted truss head, 5/16 NC x 1/2 inch
2шт.
15
186697A1
SUPPORT
BRACKET - shield mounting, upper
1шт.
16
1308914C4
SUPPORT
- straw spreader, left-hand shield
1шт.
17
237966A1
SUPPORT
BRACKET - shield (Replaces bracket 141203A2)
1шт.
18
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
- serrated slotted truss head, 5/16 NC x 3/4"
3шт.
19
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
3шт.
20
409-7516
BOLT,Hex Flg, 5/16" - 18 x 1", Spcl
1шт.
21
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
2шт.
22
477-73116
SERRATED SCREW,Truss HD, 5/16" - 18 x 1"
BOLT - serrated slotted truss head, 5/16 NC x 1 inch
3шт.
23
495-11034
WASHER,5/16", SAE
5/16" SAE (flat, 11/32 x 11/16 x 1/16")
6шт.
24
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
6шт.
25
190801A3
SUPPORT
BRACKET - shield mounting, lower
1шт.
26
610784R1
SPLIT PIN/SAFETY PIN,2.4mm OD x 60.345mm OAL
PIN - locking
1шт.
27
191030A1
STRIP
- foam
1шт.
28
140286A1
STRIP
- steel, shield front, straw and chaff spreader
2шт.
29
140287A1
STRIP
- steel, shield rear, straw and chaff spreader
2шт.
30
181940A3
GUARD
SHIELD - shaker arm, right-hand rear
1шт.
31
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
2шт.
32
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
2шт.
33
178352A1
STUD
- bail style, shield fastener, if used
1шт.
34
1981869C1
WASHER
WASHER - retainer, if used
1шт.
35
A36042
CLIP
RETAINER - quarter turn, if used
1шт.
36
187884C1
SEALING STRIP,50mm L
- 2 inch (51 mm) long, cut from 87281C1 bulk seal below
1шт.
37
1321640C1
GROMMET
- cover
2шт.
87281C1
RUBBER STRIP,38mm W x 749mm L x 19mm Thk
- bulk, 600 inch (15240 mm) long
1шт.
Выбрано товаров: 39
