Артикул
Название
Примечание
Количество
1
143651A1
SHIELD
- inlet, right-hand
1шт.
2
142450A2
SUPPORT
BRACKET - fan inlet shield, lower
1шт.
3
409-7816
BOLT,Hex Flg, 1/2" - 13 x 1", Spcl
- hex serrated flange, 1/2 NC x 1 inch
2шт.
4
231-5148
FLANGE NUT,Flg, USR, 1/2"-13
2шт.
5
142451A2
SUPPORT
BRACKET - fan inlet shield, side
1шт.
5a
27825R1
SPACER,8.5mm ID x 12.7mm OD x 12.7mm L
2шт.
6
409-7520
BOLT,Hex Flg, 5/16" - 18 x 1 1/4", Spcl
- hex serrated flange, 5/16 NC x 1-1/4 inch
4шт.
7
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
4шт.
8
143664A2
SUPPORT
BRACKET - fan inlet shield, outer
1шт.
9
143666A2
SUPPORT
BRACKET - fan inlet shield, inner
1шт.
12
409-7612
BOLT,3/8"-16 x 1.09" OAL
6шт.
13
231-5146
FLANGE NUT,3/8"-16
6шт.
14
409-7512
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
- hex serrated flange, 5/16 NC x 3/4 inch
2шт.
15
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
NUT - hex serrated flange, 5/16 inch NC
2шт.
16
143680A2
SUPPORT
- door, lower hinge
1шт.
17
413-1024
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5
2шт.
18
143676A2
SUPPORT
- door, upper hinge
1шт.
19
142455A1
TUBE,13.5 mm ID
SUPPORT - shield, right hand
1шт.
20
409-7812
BOLT,Hex Flg, 1/2" - 13 x 3/4", Spcl
- hex serrated flange, 1/2 NC x 3/4 inch
1шт.
21
231-5148
FLANGE NUT,Flg, USR, 1/2"-13
1шт.
22
189391A1
GUARD
SHIELD - door, right-hand, includes decals, see page 9H-37 for decals
1шт.
Выбрано товаров: 21
