Запчасти Case IH 1688 (2-12) - ROTARY AIR SCREEN CHUTE (01) - ENGINE

1

1979861C2

TRAP DOOR

radiator access

1шт.

2

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

BOLT serrated slotted truss head, 5/16 NC x 1/2 inch

95шт.

3

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

96шт.

4

1977216C2

SEAL

flange, 38-9/16 inch (980 mm) long

1шт.

5

1347199C2

GUIDE

radiator door

1шт.

6

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

1шт.

7

1979919C1

STEM

ROD door

1шт.

8

437157R1

SNAP RING,#37, Ext

#37, Ext

1шт.

9

95-21044

WASHER,3/8"

flat, 7/16 x 1 x 5/64 inch

3шт.

10

1302494C2

LATCH

access door

1шт.

11

118059A3

ANGLE

deflector, replaces 118059A1 and 118059A2

1шт.

12

199953C1

SELF-TAP SCREW,HWH, 5/16" - 18 x 13/16"

15шт.

12a

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

6шт.

13

495-61041

WASHER,10.31mm ID x 25.4mm OD x 1.6mm Thk

5-16шт.

13a

495-81024

WASHER,17/32" x 1 1/4" x .060"

flat, 17/32 x 1-1/4 x 1/16 inch

6шт.

14

1979860C3

DEFLECTOR

screen chute

1шт.

15

118088A2

CHUTE (DOWNWARD)

air screen

1шт.

16

118057A1

SUPPORT

radiator clean out

1шт.

17

111253A2

SUPPORT

lower, inner rear, replaces 111253A1

1шт.

18

118415A2

ANGLE

radiator upper seal

1шт.

20

1541788C3

SUPPORT

lower, rear, replaces 1541788C2

1шт.

21

1970461C1

GROMMET

rubber, 1-3/8 x 2 x 5/16

2шт.

22

1989205C2

SHIELD

PANEL side, front

1шт.

23

NSS

NOT SOLD SEPARAT

SEAL 37-1/2 inch, hinge, cut from 1338148CX bulk, see this Figure

1шт.

24

1979853C2

CHUTE (DOWNWARD)

bottom rear outlet

1шт.

25

1317704C1

SUPPORT

top chute mounting

1шт.

26

118082A2

SUPPORT

screen chute, rear, replaces 118082A1

1шт.

27

1541858C2

SUPPORT

screen, upper

1шт.

28

1302758C1

PLUG

plastic

1шт.

29

1968548C1

SUPPORT

BRACKET chute, discharge side

1шт.

30

1968546C2

SUPPORT

discharge chute

1шт.

31

1338012C1

BRUSH, COMMUTATOR

BRUSH block off

1шт.

32

151-507

RIVET,Pop, 1/8" x .575"

break mandrel, 1/8 x 1/2 inch

2шт.

33

1315670C3

SEAL

29 inch (738 mm) long, if used

2шт.

33a

128719A1

SEAL

RUBBER SEAL 31-7/8 inch (810 mm) long, cut from F43996 bulk, see this Figure, if used

2шт.

34

1251832C2

HANDLE

assist

1шт.

35

1979918C1

HANDLE

assist

1шт.

36

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

4шт.

37

D81147

SPACER

1/2 x 3/4 x 1-1/4 inch

1шт.

38

1347460C1

DOOR SEAL,648mm L

25-1/8 inch (648 mm) long

2шт.

39

1347430C1

SUPPORT

BRACKET latch retainer

1шт.

40

135270

SERRATED SCREW,5/16" - 18 x 3/4"

slotted truss head, 5/16 NC x 3/4 inch

2шт.

41

205-82

HOLE PLUG BUTTON,13/32"

button, 13/32 inch ID

1шт.

42

205-77

HOLE PLUG BUTTON,11/32"

button, 11/32 inch ID

2шт.

43

118083A4

COVER

upper, radiator, replaces 118083A2 and 118083A3

1шт.

44

199953C1

SELF-TAP SCREW,HWH, 5/16" - 18 x 13/16"

5шт.

45

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

3шт.

46

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

3шт.

47

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

6шт.

48

1302414C1

DRAG LINK

BAR cover support

1шт.

49

199953C1

SELF-TAP SCREW,HWH, 5/16" - 18 x 13/16"

1шт.

50

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

1шт.

51

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

1шт.

52

119889A1

ANGLE

radiator cover

1шт.

53

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

2шт.

54

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

2шт.

1338148CX

SEAL

bulk, foam, adhesive backed, 600 inch (15240 mm) long

1шт.

F43996

RUBBER SEAL,25.4mm W x 932.179mm L x 19.05mm Thk

RUBBER SEAL bulk, adhesive backed, 3/4 (19) x 1 (25) x 36-3/4 inch (932 mm) long

1шт.
