Запчасти Case IH 1688 (9H-34) - DECALS, GENERAL INSTRUCTIONS (12) - CHASSIS

1

A189007

DECAL

warranty, fuel pump, English

4шт.

2

184445C1

DECAL

dual wheel nut torque instructions

4шт.

3

1312487C1

PRODUCT GRAPHIC

DECAL platform leveling indicator

1шт.

4

186671C4

DECAL

lubrication guide recommended hours, right hand

1шт.

4

1300121C4

DECAL

lubrication guide recommended hours, right hand (French)

1шт.

4

1300483C2

DECAL

lubrication guide recommended hours, right hand (Spanish)

1шт.

4

1300484C2

DECAL

lubrication guide recommended hours, right hand (German)

1шт.

5

186672C4

DECAL

lubrication guide recommended hours, left hand

1шт.

5

1300122C4

DECAL

lubrication guide recommended hours, left hand (French)

1шт.

5

1300561C4

DECAL

lubrication guide recommended hours, left hand (Spanish)

1шт.

5

1300560C4

DECAL

lubrication guide recommended hours, left hand (German)

1шт.

6

1327687C2

DECAL

lubrication guide recommended hours, upper

1шт.

6

1327688C2

DECAL

lubrication guide recommended hours, upper (French)

1шт.

6

1327689C2

DECAL

lubrication guide recommended hours, upper (Spanish)

1шт.

6

1327690C2

DECAL

lubrication guide recommended hours, upper (German)

1шт.

7

179245C1

DECAL

lubrication 10 hour

1шт.

8

188217C1

PRODUCT GRAPHIC

DECAL concave indicator

1шт.

9

1312068C1

DECAL

DECAL concave indicator, export only

1шт.

10

1300129C1

DECAL

concave indicator (French)

1шт.

10

1300372C1

DECAL

concave indicator (German)

1шт.

10

1300373C1

DECAL

concave indicator (Spanish)

1шт.

11

185036C1

PRODUCT GRAPHIC

DECAL grain tank unloader

1шт.

11

1300059C1

DECAL

grain tank unloader (French)

1шт.

11

1300343C1

DECAL

grain tank unloader (Spanish)

1шт.

11

1300342C1

DECAL

grain tank unloader (German)

1шт.

12

184649C1

PRODUCT GRAPHIC

DECAL stone retarder adjustment

2шт.

12

1300110C1

DECAL

stone retarder adjustment (French)

2шт.

12

1300365C1

DECAL

stone retarder adjustment (Spanish)

2шт.

12

1300364C1

DECAL

stone retarder adjustment (German)

1шт.

13

184863C2

PRODUCT GRAPHIC

DECAL drum lower stop

2шт.

13

1300111C2

DECAL

drum lower stop (French)

2шт.

13

1300389C1

DECAL

drum lower stop (Spanish)

2шт.

13

1300388C1

DECAL

drum lower stop (German)

1шт.

14

J910778

DECAL

caution, open during fill, aftercooler

1шт.
