Запчасти Case IH 1680 (9H-06) - ENGINE SHIELD AND SERVICE DECK, P.I.N. JJC0047031 AND AFTER (12) - CHASSIS

1

186105C1

CHANNEL

- grain tank rear upper left

1шт.

2

193435C1

SUPPORT

- engine service deck

1шт.

3

192959C5

CHANNEL

SUPPORT - deck

5шт.

4

186569C5

ANGLE

- support, deck left

1шт.

5

188275C1

SUPPORT

- deck

2шт.

6

1979830C1

SUPPORT

- deck

1шт.

9

192961C6

ANGLE BAR

SUPPORT - right deck (Replaces 192961C5)

1шт.

10

193146C3

ANGLE

- engine deck rear

1шт.

11

1979828C1

PLATE

- front, engine compartment (Replaces 1347447C1)

1шт.

12

1979827C1

PLATE

- engine compartment (Replaces 1347445C1)

1шт.

13

1977155C1

DOOR

- service deck

1шт.

14

D55216

PAD,2" x 9"

STRIP - anti-skid pad (If equipped)

1шт.

17

186106C1

CHANNEL

ANGLE - shield stiffener, left upper

1шт.

18

1330483C1

SUPPORT

- trim, rear upper left, Start Serial: JJC0047918

1шт.

18

1347037C1

SUPPORT

- trim, rear upper left, Serial Range: -JJC0047918

1шт.

19

1330481C2

SUPPORT

- LH Rear, Upper shield

1шт.

20

1979810C1

SUPPORT

- door and hood

1шт.

21

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

- slotted truss head, 5/16 NC x 1/2 inch

18шт.

22

194477C2

HINGE

- rotor door cover front

1шт.

23

194478C1

ROD

- rotor door hinge

1шт.

24

186197C93

TRAP DOOR

DOOR ASSEMBLY - engine and rotor drive

1шт.

25

160638C1

HANDLE

- rotor door

1шт.

26

1302413C1

PROP

LINK - door hold up front

2шт.

28

1330428C6

SHEET ASSY.

SUPPORT - top cover, rear

1шт.

29

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

- hex flange lock, 5/16 inch NC

1шт.

30

135270

SERRATED SCREW,5/16" - 18 x 3/4"

- slotted truss head, 5/16 NC x 3/4 inch

75шт.

31

1970113C1

PROTECTION PLATE

SUPPORT - engine, rear left

1шт.

32

1970447C2

SUPPORT ASSY.

SUPPORT - air cleaner

1шт.

33

186695C1

HINGE

- door separator drive housing

3шт.

35

196438C1

SUPPORT

- clutch oil cooler front

1шт.

36

1319860C1

PLATE

- oil cooler (If equipped)

2шт.

39

196446C2

ANGLE

- clutch oil cooler support

1шт.

40

106969R1

WASHER

- flat, 11/32 x 1-1/2 x 3/64 inch

1шт.

44

1319696C1

BRACKET

ANGLE - cooler shield support

2шт.

46

281-1478

SELF-TAP SCREW,1/4" - 20 x 1/2"

SCREW - self-tapping, hex washer head, 1/4 NC x 1/2 inch

10шт.

47

1345275C1

SHIELD

PLATE - oil cooler (Replaces 196442C2 and 196448C3)

1шт.

1979316C2

SUPPORT

- engine compartment door

1шт.
