Запчасти Case IH 1680 (4-074) - FEEDER REVERSER HARNESS (06) - ELECTRICAL

1

245957C1

HARNESS

ASSEMBLY - feeder reverser

1шт.

2

453453C1

SWITCH

- feeder reverser, push button

1шт.

3

245927C91

STARTING MOTOR

MOTOR - feeder reverser (See Figure 4-76)

1шт.

3

245927C93R

REMAN-STARTER

Reman for New PN 245927C91

1шт.

3

245927C93C

CORE-STARTER

Return Number

1шт.

4

413-636

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

- hex, 3/8 NC x 2-1/4 inch

3шт.

5

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

- hex flange lock, 3/8 inch NC

3шт.

6

261-1478

SELF-TAP SCREW,Cross Pan Hd, 1/4" x 1/2"

SCREW - pan head tap, 1/4 x 1/2 inch

2шт.

7

245955C4

CABLE

- battery positive

1шт.

245955C4, THIS IS A BOLT-ON TYPE CABLE, THE SAME CABLE IN THE CLAMP, TYPE IS 92024C2.

1шт.

10

R14668

CLAMP

CLIP - rubber cushioned

10шт.

11

A39079

SOLENOID

SWITCH ASSEMBLY - magnetic relay

1шт.

12

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

2шт.

13

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

14

120614

NUT,Hex, #10 - 32

NUT, #10-32

1шт.

15

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

WASHER, LOCK, #10

1шт.

16

702093C1

CABLE TIE

STRAP - tie

1шт.
