Артикул
Название
Примечание
Количество
1
1994820C1
HARNESS
console, Serial Range: -JJC0105560
1шт.
1a
114976A2
HARNESS
console, Start Serial: JJC0105560
1шт.
2
281-6456
SELF-TAP SCREW,Hex Wash Hd, #10 x 3/8"
self tapping, hex washer head, No. 10 NF x 3/4 inch
10шт.
2
261-13512
SELF-TAP SCREW,Cross Pan Hd, #10 x 3/4"
self tapping, pan Phillips, No. 10 NC x 3/4 inch
2шт.
3
1252476C1
SWITCH
ignition, key starting
1шт.
4
131313C1
KEY, IGNITION
starting switch
1шт.
5
245219C1
SWITCH
rotor speed, Serial Range: -JJC0105560
1шт.
5a
113971A1
SWITCH
rotor speed, Start Serial: JJC0105560
1шт.
6
375431R1
LOCK WASHER
flat, special, 19/32 x 1 x 1/8 inch
1шт.
7
365502R1
NUT
flat hex, special
1шт.
10
245854C1
BUZZER
ALARM audible
1шт.
11
1301175C1
SWITCH
reel lift control
1шт.
12
342-10610
SCREW,Cross Oval Hd, #6-32 x 5/8"
machine, oval Phillips, No. 6 NC x 5/8 inch
2шт.
13
453453C1
SWITCH
push button, feeder reverser
1шт.
14
1983394C2
RELAY
electrical, 12 volt, replaces 146461C1
7шт.
16
281-1476
SELF-TAP SCREW,Hex Washer, 1/4" - 20 x 3/8"
self tapping, hex washer head, 1/4 NC x 3/8 inch
1шт.
17
299277C91
CLIP
CLAMP console harness
2шт.
19
281-6456
SELF-TAP SCREW,Hex Wash Hd, #10 x 3/8"
self tapping, hex washer head, No. 10 NF x 3/4 inch
2шт.
20
1994871C1
GOVERNOR
RECTIFIER central load dump
1шт.
23
1964919C1
IGNITION SWITCH
feeder clutch, Serial Range: -JJC0105560
1шт.
23a
122332A1
SWITCH
feeder clutch, Start Serial: JJC0105560
1шт.
24
245632C1
SWITCH
separator clutch
1шт.
25
245435C1
FUSE HOLDER
BLOCK for terminal, see Fig. 4-40 for correct assembly
1шт.
28
NSS
NOT SOLD SEPARAT
BRACKET feedback module mounting order 1994820C1
1шт.
29
107655C1
SOLENOID SWITCH
SWITCH magnetic, cab power, Includes: Ref. 30 thru 33
1шт.
31
492-11010
LOCK WASHER,#10
1шт.
32
425-105
NUT,5/16"-18, G5
2шт.
34
399470R1
BOOT
cable
2шт.
35
1994819C1
RELAY
time delay
1шт.
37
453453C1
SWITCH
push button, ether start
1шт.
38
245012C1
SWITCH
rocker, 4 wheel drive
1шт.
39
245012C1
SWITCH
rocker, two speed, variable propulsion
1шт.
40
245219C1
SWITCH
fan speed, Serial Range: -JJC0105560
1шт.
40a
245336C1
SWITCH
fan speed, Start Serial: JJC0105560
1шт.
41
260-1448
SELF-TAP SCREW,Cross Pan Hd, #8 x 1/2"
self tapping, pan Phillips, No. 8-18 x 1/2 inch
2шт.
42
245334C1
PLUG
panel switch cover
1шт.
43
245653C2
SWITCH
reel speed manual
1шт.
44
1301036C1
BUTTON
KNOB control, reel speed switch
1шт.
45
245509C1
SWITCH
reel, fore and aft
1шт.
46
245871C1
BRACKET
circuit breaker
1шт.
47
245765C1
CIRCUIT-BREAKER,30A
30 ampere, work lamp and blower
2шт.
48
276-1458
SELF-TAP SCREW,Hex Hd, #10 x 1/2"
2шт.
49
245763C1
CIRCUIT-BREAKER,20A
20 ampere, cab
2шт.
50
245860C1
BAR
circuit breaker
2шт.
51
107200C2
LIGHT SWITCH
lamp, head
1шт.
52
492-11010
LOCK WASHER,#10
8шт.
53
363660R1
CLIP
CLAMP twisted, console harness
1шт.
54
135270
SERRATED SCREW,5/16" - 18 x 3/4"
slotted truss head, 5/16 NC x 3/4 inch
1шт.
56
92065C1
GROMMET
rubber, console harness
1шт.
57
937059R1
SCREW,Serr, M10 x 70mm, Cl 10.9
slotted truss head, 1/4 NC x 1/2 inch
1шт.
59
121770C2
TRANSMITTER
MODULE low coolant
1шт.
63
1345209C1
HARNESS
seat switch
1шт.
64
195804C1
GROMMET
1/2 inch
1шт.
65
1983395C1
IGNITION SWITCH
seat
1шт.
66
440-1258
SCREW,Cross Pan Hd, 1/4"-20 x 1/2"
2шт.
67
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
1шт.
79
1983568C1
BUZZER
ALARM grain tank level
1шт.
Выбрано товаров: 61
