Запчасти Case IH 1665 (04) - BRAKE PEDAL LINKAGE (33) - BRAKES & CONTROLS

1

F30119

ROD - brake, R.H. lower

1шт.

25-155

JAM NUT,Jam, 5/16"-24, G5

- 5/16" N.F. hex. jam

2шт.

2

213-3

ADJUSTABLE CLEVIS,5/16"-24

CLEVIS

2шт.

3

O5341CS

PIN - clevis

2шт.

132-45

COTTER PIN,1/8" x 5/8"

Pin, Split (Cotter), 1/8" x 5/8"

2шт.

4

F1736

BELLCRANK - R.H. brake

1шт.

5

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease

1шт.

6

B18206

SNAP RING,#87, Ext

Ring, Snap, (retaining F1736) #87, Ext

1шт.

7

F3089

YOKE - for F1736 and F88651

2шт.

25-117

NUT,7/16"-20, G5

- 7/16" NF hex.

2шт.

8

141-5

CLEVIS PIN,7/16" x 1.190"

PIN - clevis, for F3089

2шт.

132-48

COTTER PIN,1/8" x 1"

Pin, Split (Cotter), 1/8" x 1"

2шт.

9

F1735

BELLCRANK - R.H. brake

1шт.

10

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease

1шт.

11

V30094

PLUG

SPACER - for F1735 bellcrank

1шт.

14-1040

BOLT,Hex, 5/8" - 18 x 2-1/2", Gr 5

- 5/8" x 2-1/2" N.F. hex.

1шт.

25-1110

NUT,5/8"-18, G5

- 5/8" N.F. hex; and l.w. (92-10)

1шт.

12

F88682

ROD - brake, R.H. upper (w/clevis)

1шт.

25-155

JAM NUT,Jam, 5/16"-24, G5

- 5/16" N.F. hex. jam

1шт.

13

213-3

ADJUSTABLE CLEVIS,5/16"-24

CLEVIS - upper

1шт.

14

O5341CS

PIN - clevis

2шт.

132-45

COTTER PIN,1/8" x 5/8"

Pin, Split (Cotter), 1/8" x 5/8"

2шт.

15

F88680

ROD - brake, L.H. upper (w/clevis)

1шт.

25-155

JAM NUT,Jam, 5/16"-24, G5

- 5/16" N.F. hex. jam

1шт.

16

213-3

ADJUSTABLE CLEVIS,5/16"-24

CLEVIS - upper

1шт.

17

O5341CS

PIN - clevis

2шт.

132-45

COTTER PIN,1/8" x 5/8"

Pin, Split (Cotter), 1/8" x 5/8"

2шт.

18

F88651

BELLCRANK - L.H. brake

1шт.

19

219-16

LUBE NIPPLE,5/16" NPTF

FITTING - grease

1шт.

20

F30106

PIN - (for F88651 bellcrank)

1шт.

132-52

COTTER PIN,1/8" x 1 1/2"

Pin, Split (Cotter), 1/8" x 1 1/2"

2шт.
