Запчасти Case IH 1665 (10) - TRANSMISSION GEARS, SHIFTER FORK AND SHAFTS (14) - MAIN GEARBOX & DRIVE

1

F30309

SHAFT - 1st speed and reverse shift

1шт.

2

F3167

FORK - 1st speed and reverse shift

1шт.

3

F18127

SCREW - trans. gear shift fork lock

2шт.

391-616

LOCKWIRE - gear shift fork

2шт.

4

F9736

SCREW

2шт.

5

L114099

WASHER,13.64mm ID x 21.21mm OD x 1.59mm Thk

GASKET - trans. gear shift lock

2шт.

6

F9793

SPRING - trans. gear shift lock ball

2шт.

7

211-12

BALL,7/16 Dia

- trans. gear shift lock

4шт.

8

A50421

OIL SEAL,19.05mm ID x 31.95mm OD x 6.73mm Thk

OIL SEAL

4шт.

9

F30308

SHAFT - 2nd. and 3rd. speed gear shift

1шт.

10

F3168

FORK - 2nd and 3rd speed gear shift

1шт.

11

F1751

CAP - inter. shaft brg., intermediate

1шт.

12

F30305

GASKET - inter. shaft brg. cap, intermediate

1шт.

13

39337

BEARING - inter. shaft, intermediate

1шт.

14

F30295

SNAP RING - main and inter shaft brg., intermediate

1шт.

15

F3174

GEAR - 2nd and inter. drive (19T), intermediate shaft

1шт.

16

F9836

SNAP RING, intermediate shaft

1шт.

17

40265

ROLLER BEARING

BEARING - inter. shaft roller, intermediate

1шт.

18

F30311

RETAINER - inter. shaft brg., intermediate shaft

1шт.

F30338

CAP SCREW, intermediate shaft

3шт.

391-622

LOCKWIRE - Brg. Ret. capscrew, intermediate shaft

1шт.

19

F30319

SEAL

SPACER - intermediate shaft

1шт.

20

F3179

GEAR - aux. drive, intermediate shaft

1шт.

21

F1750

CAP - diff. dr. gear brg., differential pinion shaft

1шт.

22

F30302

SHIM - .010 diff. dr. gear, differential pinion shaft

1шт.

F30303

SHIM - .005 diff. dr. gear, differential pinion shaft

2шт.

F30304

SHIM - .003 diff. dr. gear, differential pinion shaft

3шт.

23

O4300BF

ANGLE BAR

CUP - diff. dr. gear bearing, differential pinion shaft

2шт.

24

O1456AB

CONE

- diff. dr. gear bearing, differential pinion shaft

2шт.

25

F3176

GEAR - diff. drive (16T), differential pinion shaft

1шт.

26

F3175

GEAR - diff. inter (29T), differential pinion shaft

1шт.

27

F18199

SNAP RING - diff. dr. gear bearing, differential pinion shaft

1шт.

28

F1752

CAP - trans. input dr. gear brg., power input drive shaft

1шт.

113-301

BOLT (SPREADER)

CAPSCREW - input dr. gear bearing cap, power input drive shaft

3шт.

29

F30292

SEAL - oil (input dr. gear), power input drive shaft

1шт.

30

B18215

BALL BEARING,1.5748" ID x 3.1496" OD x 0.7087"

BEARING - input dr. gear ball, power input drive shaft

1шт.

31

F3170

GEAR - trans. input dr. (21T), power input drive shaft

1шт.

32

A29183

BALL BEARING,34.99mm ID x 71.99mm OD x 16.94mm W

BEARING - input dr. gear, power input drive shaft

1шт.

33

F30285

BEARING - main shaft, sliding gear

1шт.

34

F3166

SHAFT - trans. main, sliding gear

1шт.

35

F30295

SNAP RING - main & inter shaft brg., sliding gear

1шт.

36

F3173

GEAR - 1st and reverse sliding (44T), shaft

1шт.

37

F3172

GEAR - 2nd and 3rd sliding (30-17T), shaft

1шт.

38

F9836

SNAP RING, sliding gear shaft

2шт.

39

40265

ROLLER BEARING

BEARING - main shaft, sliding gear

1шт.

40

F30311

RETAINER - main shaft brg., sliding gear

1шт.

F30338

CAP SCREW, sliding gear shaft

3шт.

391-622

LOCKWIRE - Brg. Ret. Capscrew, sliding gear shaft

1шт.

41

F30319

SEAL

SPACER - main shaft, sliding gear

1шт.

42

F3178

GEAR - aux. driven, sliding gear shaft

1шт.

43

F30279

SPACER, sliding gear shaft

1шт.

44

B18274

BALL BEARING,1.7712" ID x 3.3465" OD x 0.748"

BEARING - countershaft, power transfer shaft

2шт.

45

F3171

GEAR - trans. countershaft (31-44-17T), power transfer shaft

1шт.
