Запчасти Case IH 1660 (9B-22) - CONE (14) - ROTOR, CONCANVES & SIEVE

1

188029C1

LATCH

- front door

2шт.

2

496-21041

WASHER,13/32" x 13/16" x .089", HDN

- flat, 13/32 x 13/16 x 3/32", hardened

4шт.

3

432-816

COTTER PIN,1/8" x 1"

1/8" x 1"

2шт.

4

M296

SPRING

- front door latch

2шт.

5

193436C3

INSPECTION DOOR

DOOR - separator, front

1шт.

6

160638C1

HANDLE

- door, front

1шт.

7

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

- serrated slotted truss head, 5/16 NC x 3/4"

2шт.

8

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

2шт.

12

1300208C91

DOOR

ASSEMBLY - access, rotor front, no longer available, order door 1302515C1, item 13, Includes: decal listed below

1шт.

REF

INSTRUCTION

DECAL - danger, See Figure 9H-34

1шт.

13

1302515C1

DOOR

- access, rotor front

1шт.

14

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

- serrated slotted truss head, 5/16 NC x 3/4"

5шт.

15

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

5шт.

18

194047A2

CONE

- transition, corn and grain (Replaces cone 1317770C2)

1шт.

18

198101A2

CONE

- transition, rice (Replaces cone 1309419C2)

1шт.

19

154273C1

BOLT,Hex Serr, 3/8" - 16 x 1", Spcl

- hex, self-locking, special, 3/8 NC x 1 inch, corn and grain

4шт.

19

409-7820

BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl

Rice Hex Flg, 1/2"-13 x 1 1/4", Serr

4шт.

20

231-5146

FLANGE NUT,3/8"-16

Corn and grain Flg, USR, 3/8"-16

4шт.

20

231-5148

FLANGE NUT,Flg, USR, 1/2"-13

Rice Flg, USR, 1/2"-13

4шт.

21

195202C1

SEAL

- feeder

2шт.

22

195409C1

PLATE

- with weld bolt, seal backup

2шт.

23

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

6шт.
