Запчасти Case IH 1660 (8-006) - HYDRAULIC RESERVOIR DRAIN, PRIOR TO P.I.N. JJC0103800 (07) - HYDRAULICS

1

1301237C92

RESERVOIR

ASSEMBLY - hydraulic, parts list Figure 8-002

1шт.

2

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

8-1, 90 Duro, .644" ID x .087" Thk

1шт.

3

196816C1

FITTING

ADAPTER - barb stem

1шт.

4

214-1412

HOSE CLAMP,#12, 0.69" - 1.25", Type F Worm

CLAMP, HOSE, #12, 0.69/1.25 Type F Worm

2шт.

5

NSS

NOT SOLD SEPARAT

HOSE - oil, 178 mm (7 inch) long, cut from bulk hose S118576X below

1шт.

6

187822C1

HYD TUBE,5/8" OD, 14, 1.2" Length

TUBE - drain

1шт.

7

218-756

CAP,37 Degree, 7/8"-14

Drain tube 37º, 7/8"-14

1шт.

8

165601C1

CLAMP

- reservoir drain tube

1шт.

9

163492C1

RUBBER INSULATOR

INSULATOR - rubber, 5/8 ID x 1-13/64 inch long

1шт.

10

413-644

BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5

- hex, 3/8 NC x 2-3/4 inch

1шт.

11

231-5146

FLANGE NUT,3/8"-16

1шт.

S118576X

LARGE HOSE,15.88mm ID x 7620mm L

HOSE - bulk, rubber, 7620 mm (300 inch) long

1шт.

21

REF

INSTRUCTION

RESERVOIR ASSEMBLY - hydraulic, parts list Figure 8-004, P.I.N. JJC0103800 and after

1шт.

22

217-44

REDUCER,1/2" - 14 NPT x 3/8" - 18 NPT

P.I.N. JJC0103800 and after 1/2"-14 NPTF x 3/8"-18 Fem NPTF

1шт.

23

301803R1

SHUT-OFF VALVE

VALVE - shutoff, reservoir drain, P.I.N. JJC0103800 and after

1шт.

24

1954736C1

HOSE CLAMP,#24

CLAMP, HOSE, , Adjustable, P.I.N. JJC0103800 and after #24

2шт.

25

NSS

NOT SOLD SEPARAT

HOSE - oil, 1350 mm (53-5/32 inch) long, cut from bulk hose 1977295CX below, P.I.N. JJC0103800 and after

1шт.

26

1977169C1

TEE

- oil drain, P.I.N. JJC0103800 and after

1шт.

27

217-411

PLUG,Hex Hd, 1/2" - 14 NPT

P.I.N. JJC0103800 and after Hex Hd, 1/2"-14

2шт.

29

702093C1

CABLE TIE

STRAP - tie, P.I.N. JJC0103800 and after

1шт.

1977295CX

LARGE HOSE

HOSE - bulk, 15240 mm (600 inch) roll, sold by the foot, P.I.N. JJC0103800 and after

1шт.
