Запчасти Case IH 1660 (2-18) - ETHER START, DT466B ENGINE (01) - ENGINE

1

385064R1

START SPRAY FLUID

FLUID - ether starting, 12 ounce can, no longer available, order ZAD4 from ship direct central

1шт.

2

121842C91

SOLENOID SWITCH

SOLENOID ASSEMBLY - ether injection, no longer available, order solenoid assembly 185552A2, parts list Fig. 2-19A, Includes: Ref. 3 and 4

1шт.

3

395686R1

GASKET

- injector solenoid, 15/64 inch diameter

1шт.

3

1963571C1

GASKET

GASKET - injector solenoid, 19/32 inch diameter

1шт.

4

121851C1

RETAINER

- ether start fluid container

1шт.

5

289970C91

FITTING

ELBOW - 90 degree, special, 1/8-27 PT x 1/8 inch tube

2шт.

6

NSS

NOT SOLD SEPARAT

TUBE - solenoid to manifold, 50 inch (1270 mm) long, cut from bulk tubing 417195C2

1шт.

7

269635R91

NOZZLE CAP

NOZZLE - starting fluid

1шт.

8

477-73116

SERRATED SCREW,Truss HD, 5/16" - 18 x 1"

BOLT - serrated slotted truss head, 5/16 NC x 1 inch

2шт.

9

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

2шт.

417195C2

PLASTIC-RUBBER TUBE

TUBE - bulk, 100 foot (30480 mm) roll

1шт.
