Запчасти Case IH 1660 (5-44) - HYDRAULIC SYSTEM, POWER GUIDE AXLE, PRIOR TO P.I.N. JJC0036301 (04) - STEERING

1

1310556C91

MOTOR, ELECTRIC

MOTOR - wheel drive, parts list Fig. 5-66

2шт.

2

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk

2шт.

4

1324476C3

ELBOW

- 90 degree high pressure swivel, 1-1/16-12 thread (Replaces elbow 1324476C1)

4шт.

5

218-5231

ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw

- 90 degree, 1-1/16-12 inch flare x swivel, 1-1/16-12 thread

11шт.

6

218-5128

ELBOW,90° Elbow, 9/16" - 18 Male JIC x 3/4" - 16 Male ORB

- 90 degree, 9/16-18 flare x 3/4-16 inch adjustable O-ring boss, Incl. 6A

2шт.

6a

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

8-1, 90 Duro, .644" ID x .087" Thk

2шт.

7

218-5030

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

ADAPTER - straight, 1-1/16-12 inch flare x O-ring boss, Includes: Ref. 7A

2шт.

7a

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk

2шт.

8

218-5064

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

ADAPTER - straight, 1-1/16-12 inch flare x O-ring boss (Replaces connector 9410205), Incl. Ref. 8A

4шт.

8a

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

12-1, 90 Duro, .924 ID x .116" Thk

4шт.

9

237-6004

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk

1шт.

10

218-5053

HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB

ADAPTER - straight, 7/16-20 inch thread, 7/16-20 thread

1шт.

11

218-5352

HYD CONNECTOR,9/16"-18, 37 Degree x 7/16"-20, O-Ring

ADAPTER - straight, 9/16-18 flare x 7/16-20 inch O-ring boss, Includes: Ref. 11A

1шт.

11a

237-6004

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk

1шт.

12

218-5222

TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run

- swivel, 9/16-18 inch flare branch x flare x swivel

1шт.

13

218-836

TEE,37 Degree, 9/16"-18 x 9/16"-18, Fem Sw Br

- 9/16-18 inch swivel x flare x flare

1шт.

14

REF

INSTRUCTION

VALVE - positraction

1шт.

15

1324452C1

HOSE

- drive, 54-1/2 inch (1385 mm) long

4шт.

16

1324453C1

HOSE

- drive, 86 inch (2184 mm) long

2шт.

17

1315503C1

HOSE

- charge pressure, 1/4 ID x 75 inch (1905 mm) long

1шт.

18

1315501C1

HOSE

- pressure, 3/4 ID x 62 inch (1575 mm) long

2шт.

19

1315502C1

HYDRAULIC HOSE,9.52 mm ID x 1600.00 mm

- Drain 9.52 mm ID x 1600.00 mm

1шт.

20

326-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 8

2шт.

21

515-25238

CLAMP,15/16", Insul, 1/2" Bolt

P-type, coated (Replaces clamp 28135R1) 15/16", Insul, 1/2" Bolt

2шт.

22

329-1410

JAM NUT,Jam, 5/8"-11, G8

2шт.

23

1324474C1

PLATE

- hose clamp support

2шт.

24

232-51312

FLANGE NUT,Flg, USR, 3/4"-10

(G8) Flg, USR, 3/4"-10

2шт.

25

413-1272

BOLT,Hex, 3/4" - 10 x 4-1/2", Gr 5

- hex, 3/4 NC x 4-1/2 inch

2шт.

26

1324471C1

BRACKET

SUPPORT - bracket plate, not shown

2шт.

27

1324472C1

BRACKET

SUPPORT - hose bracket, not shown

2шт.

28

1324473C1

CLAMP

- hose, not shown

2шт.

29

1324450C1

SLEEVE

- nylon, 3-5/16 ID x 36 inch (914 mm) long

2шт.

30

1324451C1

PROTECTIVE SLEEVE,40.4 mm ID x 914.50 mm

SLEEVE, 40.40 mm ID x 914.50 mm, Nylon

2шт.
