Запчасти Case IH 1660 (010) - REEL 4 BAT (58) - ATTACHMENTS/HEADERS
№
Артикул
Название
Примечание
Количество
1
F4046
BAT - reel, 14 ft. header
4шт.
111-111
CARRIAGE BOLT,Short NK, 1/4"-20 x 1", G2
BOLT, CARRIAGE, Short NK, 1/4"-20 x 1", G2
32шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
32шт.
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
32шт.
F4048
BAT - reel, 16 ft. header
4шт.
111-111
CARRIAGE BOLT,Short NK, 1/4"-20 x 1", G2
BOLT, CARRIAGE, Short NK, 1/4"-20 x 1", G2
32шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
32шт.
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
32шт.
F4105
BAT - reel, 19 ft. header
4шт.
111-109
BOLT - 1/4" x 1-1/4" rhd. sq. nk. Short NK, 1/4"-20 x 1 1/4", G2
36шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
36шт.
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
36шт.
2
F79614
SHAFT - reel, with arm hubs (14 ft. header)
1шт.
132-154
COTTER PIN,1/4" x 2"
Pin, Split (Cotter), 1/4" x 2"
3шт.
F79616
SHAFT - reel, w/arm hubs (16 ft. hdr.) Before #8334601 (Replaced by F88299 when stock is exhausted)
1шт.
F88299
SHAFT - reel, w/arm hubs (16 ft. hdr.) #8334601 and after
1шт.
132-154
COTTER PIN,1/4" x 2"
Pin, Split (Cotter), 1/4" x 2"
3шт.
F88304
SHAFT - reel, w/arm hubs (19 ft. hdr.)
1шт.
132-154
COTTER PIN,1/4" x 2"
Pin, Split (Cotter), 1/4" x 2"
3шт.
F88621
SHAFT - reel, w/arm hubs (20 ft. hdr.)
1шт.
132-154
COTTER PIN,1/4" x 2"
Pin, Split (Cotter), 1/4" x 2"
3шт.
3
B18302
WASHER
3шт.
4
F9237
STRAP - tie, reel arm (14 ft. and 16 ft. headers)
8шт.
114-2
BOLT,Hex, 1/4" - 28 x 1/2", Gr 5
- 1/4" x 1/2" N.F. hex.
8шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
8шт.
129-121
NUT,1/4"-28, G5
8шт.
F9237
STRAP - tie, reel arm (19 ft. and 20 header)
12шт.
113-1
BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
12шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
12шт.
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
12шт.
5
F9236
ARM
- reel (14 ft. and 16 ft. headers)
16шт.
114-2
BOLT,Hex, 1/4" - 28 x 1/2", Gr 5
- 1/4" x 1/2" N.F. hex.
32шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
32шт.
129-121
NUT,1/4"-28, G5
32шт.
F14047
ARM - reel (19 ft. and 20 ft. header)
20шт.
113-1
BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
40шт.
111-109
BOLT - 1/4" x 1-1/4" rhd. sq. nk. Short NK, 1/4"-20 x 1 1/4", G2
24шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
64шт.
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
64шт.
6
F9238
CLOSURE - reel end (14 ft. and 16 ft. headers)
8шт.
114-2
BOLT,Hex, 1/4" - 28 x 1/2", Gr 5
- 1/4" x 1/2" N.F. hex.
32шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
32шт.
129-121
NUT,1/4"-28, G5
32шт.
F9238
CLOSURE - reel end (19 ft. and 20 ft. header)
8шт.
113-1
BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
40шт.
192-19
LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND
WASHER, LOCK, 1/4"
40шт.
7770
NUT,Hex, 1/4 - 20, Cl 5
1/4"-20, G5
40шт.
7
F14906
REINFORCEMENT - reel bat (14 ft. - 16 ft.)
8шт.
111-111
CARRIAGE BOLT,Short NK, 1/4"-20 x 1", G2
BOLT, CARRIAGE, , and nut (129-101) Short NK, 1/4"-20 x 1", G2
16шт.
F14912
REINFORCEMENT - reel bat (19 ft. and 20 ft. header)
8шт.
111-109
BOLT - 1/4" x 1-1/4" rhd. sq. nk., and nut (129-101) Short NK, 1/4"-20 x 1 1/4", G2
24шт.
