Запчасти Case IH 1660 (194[A]) - OIL RESERVOIR FOR HYDRAULIC SYSTEM (35) - HYDRAULIC SYSTEMS

1

F8050

HOSE - hydraulic, intake, Serial Range: reservoir-pump

1шт.

214-11

X

CLAMP - #11-1/2 hose

1шт.

2

F8049

COUPLING - for F8050 intake hose

1шт.

3

F87604

LINE - power steering valve to reservoir (see hyd. system)

1шт.

4

F87605

LINE - control valve to reservoir (see hyd. system)

1шт.

5

F77978

RESERVOIR - oil, hydraulic

1шт.

6

F77662

DIPSTICK - oil reservoir gauge

1шт.

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

4шт.

92-6

LOCK WASHER,3/8"

4шт.
