Запчасти Case IH 1660 (190) - HYDRAULIC SYSTEM (35) - HYDRAULIC SYSTEMS

1

F87869

CYLINDER - header lift (Before #8334601)

2шт.

F88359

CYLINDER - header lift (#8334601 and after)

2шт.

2

F13779

HOSE - hydraulic, connects header lift cylinders

1шт.

3

F14212

HOSE - hydraulic

1шт.

4

F14213

CLIP - hydraulic line, for Ref. 5

3шт.

5

F13781

LINE - hydraulic, valve to F14212 hose (Before #8359001)

1шт.

F30125

LINE - hydraulic, valve to F14212 hose (#8359001 and after)

1шт.

6

F88156

VALVE - control, header lift, reel lift, V.S. control

1шт.

7

F87533

LINE - hydraulic (see hydraulic reel lift)

1шт.

8

218-443

HYD CONNECTOR,9/16" - 18 Male JIC x 1/4" - 18 Male NPTF

CONNECTOR - #6 FTX-S Parker, flared

1шт.

9

F76962

RAM - variable speed control

1шт.

10

218-443

HYD CONNECTOR,9/16" - 18 Male JIC x 1/4" - 18 Male NPTF

CONNECTOR - #6 FTX-S Parker, flared

1шт.

11

F9263

CLIP - hydraulic line

2шт.

13

218-734

UNION,9/16"-18, 37 Degree x 9/16"-18, 37 Degree

- #6 HTX-S Parker, flared

1шт.

14

F13802

LINE - upper hydraulic, valve to V.S. ram

1шт.

15

F9263

CLIP - hydrualic line

4шт.

16

F87758

ADAPTOR - port assembly, for Ref. 5

1шт.

17

F87759

ADAPTOR - port assembly, for Ref. 7

1шт.

18

218-5059

HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring

CONNECTOR - #8 F50X-S Parker, flared, for Ref 19 and 36

2шт.

19

F87605

LINE - hydraulic, Serial Range: valve-reservoir

1шт.

20

F13963

HANGER - hydraulic line

2шт.

14-412

BOLT,Hex, 1/4" - 28 x 3/4", Gr 5, Full Thd

- 1/4" x 3/4" N.F. hex

2шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

2шт.

21

218-456

HYD CONNECTOR,3/4" - 16 Male JIC x 1/2" - 14 Male NPTF

CONNECTOR - #8 FTX-S Parker, flared

1шт.

22

221-414

FITTING,90 Degree, 1/2"-14, NPT

ELBOW - 1/2" NPT 90deg. street

1шт.

23

F77978

RESERVOIR - oil, hydraulic

1шт.

24

221-412

ELBOW,90 Degree, 1/4"-27, NPT

- 1/4" NPT 90deg. street

1шт.

25

218-443

HYD CONNECTOR,9/16" - 18 Male JIC x 1/4" - 18 Male NPTF

CONNECTOR - #6 FTX-S Parker, flared

1шт.

26

F87604

LINE - hydraulic, ross, Serial Range: valve-reservoir

1шт.

27

218-5058

HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB

CONNECTOR - #6-8F50X-S Parker, flared

1шт.

28

221-1405

ELBOW,45 Degree, 3/4"-14, NPT

- 3/4" NPT 45deg. street

1шт.

29

F8049

COUPLING - intake hose, hydraulic pump and reservoir

2шт.

30

F8050

HOSE - hydraulic, intake -, Serial Range: reservoir-pump

1шт.

214-11

X

CLAMP - hose (#11-1/2)

2шт.

31

221-415

ELBOW,90 Degree, 3/4"-14, NPT

Street (Intake hose coupling) 90º, 3/4"-14, NPT

1шт.

32

F86819

PUMP - hydraulic (exh. then use F88935)

1шт.

F88935

PUMP, HYDRAULIC

PUMP - hydraulic (Replaces F86819 when exh.)

1шт.

33

F12681

HOSE - hydraulic (1/4" I.D.) pressure line to steering valve

1шт.

34

F12682

HOSE - hydraulic (1/2" I.D.) pressure line to control valve

1шт.

35

F12137

CLAMP - hydraulic line (pressure lines to top deck)

1шт.

36

F87606

LINE - hydraulic, Serial Range: pump-valve

1шт.

37

F87603

LINE - hydraulic, pump to ross valve

1шт.

38

218-5057

HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB

CONNECTOR - #6-F50X-S Parker, flared

3шт.

39

A37980

VALVE

- power steering, hydrostatic

1шт.

40

F86570

PUMP - hand, hydrostatic

1шт.

41

218-5059

HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring

CONNECTOR - #8-F50X-S Parker, flared

2шт.

42

F12441

CLIP - hydraulic line

1шт.

43

F87607

LINE - hydraulic, inner, hand pump to ross valve

1шт.

44

F87608

LINE - hydraulic, outer, hand pump to ross valve

1шт.

45

218-5059

HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring

CONNECTOR - #8-F50X-S Parker, flared

2шт.

46

F13782

LINE - hydraulic, front, Serial Range: valve-cylinder

1шт.

47

F12067

CLIP - hydraulic line, for Ref. 46 and 48

1шт.

48

F13783

LINE - hydraulic, rear, Serial Range: valve-cylinder

1шт.

49

F17487

CLIP - hose, for Ref. 50

1шт.

14-4104

BOLT - 1/4" x 6-1/2" N.F. hex.

1шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

1шт.

50

F12430

HOSE - hydraulic, steering cylinder

2шт.

51

F87848

CYLINDER - power steering

1шт.

F10143

PAD - protection, hydraulic line (Not Shown)

1шт.
