Запчасти Case IH 1660 (220) - TRANSMISSION CASE AND AXLE HOUSING (14) - MAIN GEARBOX & DRIVE

1

F1272

COVER - side, case

1шт.

113-215

X

BOLT - 3/8" x 1" N.C. hex. Gr. 7-8 stl.

10шт.

92-6

LOCK WASHER,3/8"

10шт.

2

F9786

GASKET - for F1272 cover

1шт.

3

F87744

HOUSING - axle, R.H.

1шт.

4

F1939

CASE - transmission

1шт.

5

221-35

DRAIN PLUG,Sq Soc, 3/4"-14 NPTF

PLUG - 3/4" sq. socket hd. pipe

1шт.

6

F9787

GASKET - transmission case cover

1шт.

7

F1938

COVER - transmission case, lower

1шт.

221-15

PLUG,Sq Hd, 3/4"-14

- 3/4" sq. hd. pipe

1шт.

114-403

X

BOLT - 1/2" x 2-1/4" N.F. hex. Gr. 7-8 stl.

13шт.

129-545

NUT,1/2"-20, G8

13шт.

113-401

BOLT

- 1/2" x 1-3/4" N.C. hex. Gr. 7-8 stl.

5шт.

92-8

LOCK WASHER,1/2"

18шт.

8

F9750

STUD - transmission case cover

2шт.

9

F9806

STUD - transmission, Serial Range: case-axle

16шт.

129-551

SPECIAL NUT,9/16"-18, G8

STUD - transmisison case to axle

16шт.

129-551

SPECIAL NUT,9/16"-18, G8

- 9/16" N.F. hex. Gr. 8

16шт.

92-9

BEARING WASHER,9/16"

16шт.

10

T25082

BREATHER - transmissin case

1шт.

11

F9736

SCREW - gear shift lock ball spring

2шт.

12

F9817

GASKET - axle housing to case (F1939)

2шт.

13

F87743

HOUSING - axle, L.H.

1шт.

14

F88707

HUB - wheel (see drive wheels and hubs)

2шт.

15

F14992

STUD - wheel hub

8шт.

16

F13197

U BOLT - front axle

2шт.

25-1112

NUT,3/4"-16, G5

- 3/4" N.F. hex.

4шт.

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

4шт.

17

F1957

REINFORCEMENT - axle tube

2шт.

18

F13198

U BOLT - front axle, long

2шт.

25-1112

NUT,3/4"-16, G5

- 3/4" N.F. hex.

4шт.

92-12

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

4шт.

19

F13199

SPACER - pipe, main frame (for F13198)

2шт.

20

F14800

"U" BOLT - support

1шт.

195-533

WASHER,1/2", SAE

2шт.

129-125

NUT,1/2"-20, G5

4шт.

21

F88311

SUPPORT - transmission input housing

1шт.
