Запчасти Case IH 1660 (102) - MAIN COMBINE DRIVE IDLER ASSEMBLY, BELT STOP S/N8368001 AND AFTER (14) - MAIN GEARBOX & DRIVE

1

F13239

STOP - main combine drive throwout lever

1шт.

14-414

BOLT,Hex, 1/4" - 28 x 7/8", Gr 5, Full Thd

- 1/4" x 7/8" N.F. hex.

2шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

2шт.

2

F87019

LEVER - control

1шт.

3

F8185

LINK - control

1шт.

4

F13040

ANGLE - L.H. control lever support (Replaced by F14491 when stocks are exhausted)

1шт.

F14491

ANGLE - L.H. control lever support (Replaces F13040)

1шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk.

1шт.

25-104

NUT,1/4"-20, G5

1шт.

5

141-5

CLEVIS PIN,7/16" x 1.190"

PIN

2шт.

132-26

COTTER PIN

Pin, Split (Cotter), 3/32" x 3/4"

2шт.

6

F87020

SHAFT - control

1шт.

132-50

COTTER PIN,1/8" x 1 1/4"

Pin, Split (Cotter), 1/8" x 1 1/4"

1шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk.

1шт.

25-104

NUT,1/4"-20, G5

1шт.

7

F13011

SCREW

GRIP - control lever

1шт.

8

141-4

CLEVIS PIN,3/8" x 1.060"

PIN, CLEVIS, , for Ref. 11 3/8" x 1.060"

1шт.

132-26

COTTER PIN

Pin, Split (Cotter), 3/32" x 3/4"

1шт.

9

F13043

SUPPORT - control lever, R.H.

1шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk.

4шт.

25-104

NUT,1/4"-20, G5

4шт.

10

F13039

SUPPORT - control lever, center

1шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk.

1шт.

25-104

NUT,1/4"-20, G5

1шт.

11

F87536

ROD - control

1шт.

195-25

WASHER,3/8"

- SAE std. flat 3/8"

1шт.

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex.

1шт.

12

F10901

SPRING

1шт.

13

F13798

GUIDE - rod and spring

1шт.

14

F88696

STRAP - control

1шт.

15

F7914

BOLT - shoulder

1шт.

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - 1/8" str.

1шт.

16

F86602

SHEAVE - idler

1шт.

17

B18163

NEEDLE BEARING,1" ID x 1.4385" OD x 1.75"

BEARING

1шт.

18

O3739CK

X

WASHER - for F7914 bolt, Ref. 15

2шт.

19

131-36

LOCK NUT,5/8"-18

NUT - 5/8" - 18 NF Esna #29-NTE-108

1шт.

20

F88881

ARM - tightener

1шт.

131-3

LOCK NUT,5/16"-24, GB

NUT - 5/16 - 24 N.F. Esna

1шт.

219-400

LUBE NIPPLE,45 Degree Elbow, 1/4" - 28

FITTING - 1/4" - 28 grease

1шт.

21

F60940

SPRING

- disengagement

1шт.

21a

F6940

SPRING - disengagement

1шт.

22

195-49

WASHER

- 7/8" plain

1шт.

23

F30350

GUIDE - operating rod, Start Serial: 8368001

1шт.

24

F30348

ROD - operating, Start Serial: 8368001

1шт.

195-25

WASHER,3/8"

- Sae. Std. 3/8", Start Serial: 8368001

1шт.

25

F30349

COLLAR - belt stop, Start Serial: 8368001

1шт.

85-512

SET SCREW

- 5/16" Sq. hd. N.C., Start Serial: 8368001

1шт.

25-155

JAM NUT,Jam, 5/16"-24, G5

- 5/16" Jam N.F. hex., Start Serial: 8368001

1шт.

26

F6181

SPRING, Start Serial: 8368001

1шт.

27

F30347

PLATE - side, belt stop, Start Serial: 8368001

2шт.

111-125

BOLT - 1/4" x 3/4" rhd. sq. nk. N.C., nut & lockwasher, Start Serial: 8368001

4шт.

111-201

BOLT - 5/16" x2-3/4" rhd. sq. nk. N.F., Start Serial: 8368001

1шт.

131-3

LOCK NUT,5/16"-24, GB

NUT - 5/16" - 24 N.F. Esna, Start Serial: 8368001

1шт.

28

F88892

SUPPORT - assy. belt stop, Start Serial: 8368001

1шт.

14-616

BOLT,Hex, 3/8" - 24 x 1", Gr 5

- 3/8" x 1" N.F. hex., Start Serial: 8368001

2шт.

195-25

WASHER,3/8"

- flat 3/8", Start Serial: 8368001

2шт.

92-6

LOCK WASHER,3/8"

, Start Serial: 8368001

2шт.

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex., Start Serial: 8368001

2шт.

29

F30346

LOOP - belt stop, Start Serial: 8368001

1шт.
