Запчасти Case IH 1660 (244) - THROTTLE CONTROL LINKAGE, BEFORE S/N 8359001 (10) - ENGINE

1

F12984

SPACER - throttle control

1шт.

2

111-124

BOLT - 1/4" x 8" rhd. sq. nk.

1шт.

195-21

WASHER,5/16"

- SAE std. flat (Not shown) for Ref. 2 5/16"

1шт.

3

195-18

WASHER,1/4"

- SAE std. flat 1/4"

1шт.

4

92-5

LOCK WASHER,5/16"

LOCKWASHER - 1/4" SAE std.

1шт.

5

25-104

NUT,1/4"-20, G5

1шт.

6

F87026

ARM - throttle control

1шт.

7

14-424

SCREW,Hex, 1/4" - 28 x 1 1/2", Gr 5

BOLT - 1/4" x 1-1/2"

1шт.

8

F13054

LEVER - throttle control

1шт.

9

F21683

KNOB

- throttle control rod

1шт.

10

A30370

SPRING - throttle control

1шт.

11

131-1

LOCK NUT,1/4"-28, GB

NUT - 1/4" Esna #29-NE-048

1шт.

12

F13962

ROD - throttle

1шт.

25-114

NUT,1/4"-28, G5

- 1/4" N..F. hex.

1шт.

132-25

COTTER PIN,3/32" x 5/8"

Pin, Split (Cotter), 3/32" x 5/8"

1шт.

13

213-2

ADJUSTABLE CLEVIS,1/4"-28 x 2"

CLEVIS - for Ref. 12

1шт.

14

141-2

CLEVIS PIN,1/4" x .770"

PIN - clevis, for Ref. 13

1шт.

15

132-5

COTTER PIN,1/16" x 1/2"

Pin, Split (Cotter), , For ref. 14 1/16" x 1/2"

1шт.

16

O1444CS

BOLT - shoulder (for bellcrank)

1шт.

17

92-6

LOCK WASHER,3/8"

1шт.

18

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex.

1шт.

19

F79438

BELLCRANK - throttle

1шт.

20

F13858

WIRE -, Serial Range: bellcrank-carburetor

1шт.

21

F14379

CLAMP

- wire (Replaces A27129)

1шт.

22

F13856

ROD - throttle, carburetor to governor (Gas)

1шт.

23

F12690

ROD - throttle, carburetor to governor (L. P.)

1шт.

129-121

NUT,1/4"-28, G5

2шт.

24

F13857

BEARING, BALL

JOINT - ball

2шт.

114-7

BOLT,Hex, 1/4" - 28 x 7/8", Gr 5, Full Thd

2шт.

192-44

LOCK WASHER

LOCKWASHER - 1/4" shakeproof

2шт.
