Запчасти Case IH 1660 (232) - DRIVE SHIELDS (90) - PLATFORM, CAB, BODYWORK AND DECALS

F12577

SHIELD - R.H. (Replaces F86694 when stock is exh.)

1шт.

1

F86694

SHIELD - R.H. (Replaced by F12577 when stock is exh.)

1шт.

2

F20976

CLIP

- hinge

4шт.

3

F12581

BRACE - R.H. rear

1шт.

4

F12580

BRACE - R.H. front

1шт.

5

114-3

BOLT,Hex, 1/4" - 28 x 5/8", Gr 5

10шт.

6

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, 1/4"

11шт.

7

129-121

NUT,1/4"-28, G5

11шт.

8

132-24

COTTER PIN,3/32" x 1/2"

PIN, SPLIT (COTTER), 3/32" x 1/2"

1шт.

9

136-154

HAIR PIN COTTER,Int, 7/64" x .072"

COTTER - hair pin

1шт.

10

F12579

LATCH - shield

1шт.

F12570

SHIELD

- L.H. (Replaces F86688 when stock is exh.)

1шт.

11

F86688

SHIELD - L.H. (Replaced fy F12570 when stock is exh.)

1шт.

12

F20976

CLIP

- hinge

3шт.

13

F86691

HANGER - L.H. shield

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

4шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

4шт.

14

F19960

LATCH

5шт.

15

117EB

SPRING

5шт.

16

7770

NUT,Hex, 1/4 - 20, Cl 5

1/4"-20, G5

10шт.

17

F13250

HANGER - shield

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

1шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

1шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

18

F12575

BRACE - L.H. front

1шт.

19

114-7

BOLT,Hex, 1/4" - 28 x 7/8", Gr 5, Full Thd

1шт.

20

F12576

BRACE - L.H. rear

1шт.

21

F87704

SHIELD - pulley, strawspreader (see page 157)

1шт.

22

F14058

SHIELD - belt and sheave, strawspreader (See page 157)

1шт.

23

F87622

SHIELD - strawwalker, belt drive assembly

1шт.

24

11-6104

BOLT - 3/8" x 6-1/2" rhd. sq. nk.

1шт.

92-6

LOCK WASHER,3/8"

1шт.

25-106

NUT,3/8"-16, G5

- 3/8" N.C. hex.

1шт.

195-525

WASHER,3/8", SAE

2шт.

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, 3/8"-16, G5

1шт.

25

O743N

SPACER - 3/8" I.D. x 4-27/32" long

1шт.

26

14-496

BOLT - 1/4" x 6" N.F. hex.

1шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

1шт.

195-518

WASHER,1/4", SAE

2шт.

192-19

LOCK WASHER,Helical Spring, 0.256" ID, CST, ZND

WASHER, LOCK, 1/4"

1шт.

129-121

NUT,1/4"-28, G5

1шт.

27

F61089

SPACER - 5/8" O.D. x 5" long

1шт.
