Запчасти Case IH 1660 (148) - GRAIN BIN DISTRIBUTION AUGER DRIVE (80) - CROP STORAGE/UNLOADING

1

F87573

SHEAVE - distribution auger (Before #8368001)

1шт.

132-99

COTTER PIN,3/16" x 2"

Pin, Split (Cotter), 3/16" x 2"

1шт.

2

126-21

WOODRUFF KEY,#A, 1/4" x 7/8"

For ref. 1 (Before #8368001) #A, 1/4" x 7/8"

1шт.

3

F86141

SPROCKET - (60T) distribution auger, driven

1шт.

4

126-21

WOODRUFF KEY,#A, 1/4" x 7/8"

For F86141, ref. 3 #A, 1/4" x 7/8"

1шт.

5

F9417

FLANGE

- for F90306 bearing, Ref 6

4шт.

6

F90306

BEARING ASSY

BEARING - for Ref. 8, F87570

2шт.

7

O4233CS

COLLAR

1шт.

8

F87570

AUGER and SHAFT - distribution (Before #8359001)

1шт.

F88685

AUGER and SHAFT - distribution (#8359001 and after)

1шт.

9

F87571

AUGER - sliding distribution

2шт.

85-512

SET SCREW

SCREW - 5/16" x 3/4" sq. hd. N.C. cup pt. set

4шт.

25-145

JAM NUT,Jam, 5/16"-18, G5

- 5/16" N.C. hex. jam

4шт.

10

F13880

SHAFT - distribution auger (Before #8368001)

1шт.

11

F85790

AUGER - sliding distribution, R.H. (Before #8358001)

1шт.

85-512

SET SCREW

SCREW - 5/16" x 3/4" sq. hd. N.C, cup pt. set

4шт.

25-145

JAM NUT,Jam, 5/16"-18, G5

- 5/16" N.C. hex. jam

4шт.

12

F87033

AUGER - sliding distribution, L.H. (Before #8368001)

1шт.

85-512

SET SCREW

SCREW - 5/16" x 3/4" sq. hd. N.C. cup pt. set

2шт.

25-145

JAM NUT,Jam, 5/16"-18, G5

- 5/16" N.C. hex. jam

2шт.

13

B18282

FLANGE

- for F90306 bearing, Ref. 14 (Before #8368001)

8шт.

11-512

SCREW,Short Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

12шт.

9635082

NUT,5/16" - 18, Gr 5

- 5/16" N.C. hex.

12шт.

92-5

LOCK WASHER,5/16"

12шт.

14

F90306

BEARING ASSY

BEARING - for F13880, Ref. 10 (Before #8368001)

4шт.

15

O4233CS

COLLAR

- (Before #8368001)

1шт.

16

2910BA

SHEAVE - driven (Before #8368001)

2шт.

132-102

COTTER PIN,3/16" x 2 1/2"

Pin, Split (Cotter), 3/16" x 2 1/2"

2шт.

17

126-21

WOODRUFF KEY,#A, 1/4" x 7/8"

For 2910BA, ref. 16 (Before #8368001) #A, 1/4" x 7/8"

2шт.

18

F11144

BRACKET - tightener (Before #8368001)

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

4шт.

92-5

LOCK WASHER,5/16"

4шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

4шт.

10

O3526CS

PULLEY

IDLER - belt (Before #8368001)

1шт.

14-840

BOLT,Hex, 1/2" - 20 x 2-1/2", Gr 5

- 1/2" x 2-1/2" N.F. hex.

1шт.

195-33

WASHER,1/2"

- SAE std. flat 1/2"

8шт.

92-8

LOCK WASHER,1/2"

1шт.

25-118

NUT,1/2"-20, G5

- 1/2" N.F. hex.

1шт.

20

13881

PIN

V-IDLER - sealed (Before #8368001)

2шт.

14-828

BOLT,Hex, 1/2" - 20 x 1-3/4", Gr 5

- 1/2" x 1-3/4" N.F. hex.

2шт.

195-33

WASHER,1/2"

- SAE std. flat 1/2"

2шт.

92-8

LOCK WASHER,1/2"

2шт.

25-118

NUT,1/2"-20, G5

- 1/2" N.F. hex.

2шт.

21

F18303

V-BELT

V-BELT, Distribution Auger Drive, Driven, Before Serial No. 8368001

1шт.
