Запчасти Case IH 1660 (142) - GRAIN BIN DRIVE (80) - CROP STORAGE/UNLOADING

1

F86732

SPROCKET - (30T) distribution auger jackshaft drive

1шт.

85-512

SET SCREW

SCREW - 5/16" x 3/4" N.C. cup pt. set

1шт.

425-145

JAM NUT,Jam, 5/16"-18, G5

1шт.

2

O227CW

KEY - (5/16" x 5/16" x 3-1/8" square)

1шт.

3

F11149

X

CHAIN - (NSS - see chain page)

1шт.

4

F7935

SPROCKET ASSY.

IDLER - jackshaft

1шт.

14-1032

BOLT,Hex, 5/8" - 18 x 2", Gr 5

1шт.

195-41

WASHER,5/8"

- SAE std. flat 5/8"

4шт.

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

25-1110

NUT,5/8"-18, G5

- 5/8" N.F. hex.

1шт.

5

F90306

BEARING ASSY

BEARING

2шт.

6

O4233CS

COLLAR

1шт.

7

F9417

FLANGE

4шт.

11-512

SCREW,Short Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

4шт.

9635082

NUT,5/16" - 18, Gr 5

- 5/16" N.C. hex.

4шт.

8

F12645

BRACKET - jackshaft bearing, inner

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

1шт.

14-510

SCREW,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

BOLT, Hex, 5/16"-24 x 5/8", G5, Full Thd

2шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

3шт.

9

F79467

SPROCKET ASSY.

SPROCKET - (30T) distribution auger jackshaft, driven

1шт.

132-99

COTTER PIN,3/16" x 2"

Pin, Split (Cotter), 3/16" x 2"

1шт.

10

126-215

KEY - #708 Hi-Pro

2шт.

11

F12647

BRACKET - idler

1шт.

12-612

BOLT - 3/8" x 3/4" rhd. sh. sq. nk.

1шт.

25-106

NUT,3/8"-16, G5

- 3/8" N.C. hex.

1шт.

14-510

SCREW,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

BOLT, Hex, 5/16"-24 x 5/8", G5, Full Thd

2шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

2шт.

12

F12648

JACKSHAFT - distribution auger drive

1шт.

13

F11143

BRACKET - jackshaft bearing, R.H.

1шт.

14-612

BOLT,Hex, 3/8" - 24 x 3/4", Gr 5, Full Thd

2шт.

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex.

2шт.

14

F86883

SPROCKET ASSY.

SPROCKET - (30T) outer jackshaft, grain bin drive

1шт.

95-410

SCREW - 1/4" x 5/8" sq. hd. N.C. cup pt. set

1шт.

25-104

NUT,1/4"-20, G5

1шт.

15

O1936HT

WASHER

3шт.

16

O3511CS

PULLEY

IDLER - chain tightener

1шт.

14-1040

BOLT,Hex, 5/8" - 18 x 2-1/2", Gr 5

- 1/2" x 1-1/2" N.F. hex.

1шт.

25-118

NUT,1/2"-20, G5

- 1/2" N.F. hex.

1шт.

17

F11144

BRACKET - adjustment, for upper elevator shaft

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

4шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

4шт.

18

F86141

SPROCKET - (60T) elevator drive, driven (Medium Speed)

1шт.

F88130

SPROCKET - (35T) elevator drive, driven (High Speed)

1шт.

126-21

WOODRUFF KEY,#A, 1/4" x 7/8"

1шт.

132-99

COTTER PIN,3/16" x 2"

Pin, Split (Cotter), 3/16" x 2"

1шт.

19

F11237

X

CHAIN - distribution auger drive, Medium Speed, (NSS - See Chain Page) Before #8368001

1шт.

F14979

CHAIN - distribution auger drive, Medium Speed (NSS - See Chain Page) #8368001 and after

1шт.

F14632

CHAIN - distribution auger drive, High Speed (NSS - see chain page)

1шт.
