Запчасти Case IH 1660 (066) - FEED RAKE UPPER SHAFT (60) - PRODUCT FEEDING

1

F11296

SNAP RING,#300, Ext

Ring, Snap, , for F86049 #300, Ext

2шт.

2

F86049

GUIDE

BLOCK - header pivot (Exhaust, then use F88589)

2шт.

F88589

GUIDE

BLOCK - header pivot (Replaces F86049)

2шт.

219-36

LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF

FITTING - grease

2шт.

3

F77924

BEARING

2шт.

4

F62107

COLLAR

1шт.

5

F1969

SPROCKET - outer

2шт.

132-104

COTTER PIN,3/16" x 3"

Pin, Split (Cotter), 3/16" x 3"

2шт.

6

F87825

SHIELD SUPPORT ASSEMBLY

4шт.

NSS

NOT SOLD SEPARAT

SUPPORT - shield

2шт.

O629HT

WASHER - lock, strap

1шт.

11-448

BOLT - 1/4" x 3" rhd. sq. nk.

2шт.

25-224

SQUARE NUT,Sq, 1/4"-20

- 1/4" N.C. sq.

2шт.

7

126-29

WOODRUFF KEY,#C, 5/16" x 1 1/8"

For Ref. 5 and 10 #C, 5/16" x 1 1/8"

3шт.

8

F13434

SHIELD

2шт.

186-71

SCREW - #12 rhd. slotted bright wood

4шт.

9

F13437

SHAFT - upper feed rake

1шт.

132-97

COTTER PIN,3/16" x 1 3/4"

Pin, Split (Cotter), 3/16" x 1 3/4"

1шт.

10

F1968

SPROCKET - center

1шт.

85-510

SCREW - 5/16" x 5/8" N.C. sq. hd. cup pt. set

1шт.

11

F87309

SUPPORT - anti-wrap shield

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

8шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

8шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

8шт.

195-18

WASHER,1/4"

- flat 1/4"

4шт.

12

F13435

SCREW

SHIELD

2шт.

13-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

4шт.

195-18

WASHER,1/4"

- flat 1/4"

4шт.

131-132

SPRING NUT,Tinn, U, 1/4"-20

- 1/4" Tinnerman speed

4шт.

13

F13388

PIN - jump clutch

3шт.

195-33

WASHER,1/2"

- SAE std. flat 1/2"

3шт.

131-710

NUT - 1/2" N.F. huglock

3шт.

14

F3148

RING - jump clutch

1шт.

114-223

BOLT - 3/8" x 5-1/2" N.F. hex.

3шт.

95-7

WASHER,7/16"

- U.S. std. 7/16"

3шт.

131-5

LOCK NUT,3/8"-16, GB

- 3/8" N.F. Esna #29-NE-064

3шт.

15

F3130

HUB - jump clutch

1шт.

16

F11313

KEY

- square

1шт.

17

F87288

SPROCKET - (34T and 48T) drives feed rake and auger drive jackshaft

1шт.

18

F11810

BUSHING

2шт.

19

F87327

X

CHAIN - drives upper feed rake shaft (NSS - see chain page)

1шт.

20

F8392

CHAIN - main header drive (NSS-see chain page) 14' - 16' - 19'

1шт.

F30050

CHAIN - main header drive (NSS-see chain page) 20 ft.

2шт.

21

S30510

SPRING

3шт.

22

F79569

SHEAVE - sickle drive

1шт.

14-836

BOLT,Hex, 1/2" - 20 x 2-1/4", Gr 5

- 1/2" x 2-1/4" N.F. hex.

3шт.

92-8

LOCK WASHER,1/2"

3шт.

25-118

NUT,1/2"-20, G5

- 1/2" N.F. hex.

3шт.

23

F10767

WASHER - (2-1/2" O.D. x 1-5/16" I.D. #16 ga.)

1шт.

24

F62050

WASHER - for bolts of F79569

3шт.

25

F13540

"V" BELT - sickle drive (14 ft. header)

1шт.

F13541

BELT

Sickle Drive, 16, 19, 20 foot Headers

1шт.
