Запчасти Case IH 1660 (060) - HEADER SUPPORT TORQUE TUBE (58) - ATTACHMENTS/HEADERS

1

F8301

GUSSET - reel support, R.H. (Replaces F13483)

1шт.

14-510

SCREW,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

BOLT, Hex, 5/16"-24 x 5/8", G5, Full Thd

3шт.

92-5

LOCK WASHER,5/16"

3шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

3шт.

2

F8344

EYEBOLT - torque tube arms

2шт.

25-118

NUT,1/2"-20, G5

- 1/2" N.F. hex.

4шт.

11-632

BOLT,Short NK, 3/8"-16 x 2", G2

- 3/8" x 2" rhd. sq. nk.

2шт.

92-6

LOCK WASHER,3/8"

2шт.

25-106

NUT,3/8"-16, G5

- 3/8" N.C. hex.

2шт.

3

F8302

GUSSET - reel support, L.H. (Replaces F13484)

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

2шт.

14-514

BOLT,Hex, 5/16" - 24 x 7/8", Gr 5, Full Thd

1шт.

92-5

LOCK WASHER,5/16"

3шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

3шт.

4

F8298

SUPPORT - torque tube (4-used w/20 ft. hdr.)

2шт.

5

F13461

SCREW

SUPPORT - torque tube

2шт.

F10320

SUPPORT - torque tube, 19 ft. header (Not Shown)

1шт.

6

F13463

SCREW

BRACKET - mounting, R. H., torque tube cover

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

2шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

2шт.

7

F13462

BRACKET - mounting, L.H., torque tube cover

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

2шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

2шт.

8

F8341

"U" BOLT - torque tube support (4 - 14 ft. and 16 ft. hrd., 5 - 19 ft. hdr. and 6 - 20 ft. hrd.

1шт.

92-6

LOCK WASHER,3/8"

1шт.

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex.

1шт.

9

F87312

TUBE - torque (for 14 ft. std. or pickup header) Replaced by F88306 when stocks are exhausted.

1шт.

F88306

TUBE - torque (for 14 ft. std. or pickup hdr.) Replaces F87312 85.12, 84.88 mm L

1шт.

F87328

TUBE - torque (16 ft. hdr.) Replaced by F88307 when stock is exhausted.

1шт.

F88307

TUBE - torque (16 ft. hdr.) Replaces F87328 97.62, 96.88 mm L

1шт.

F87329

TUBE - torque (19 ft. hdr.) Replaced by F88303 when stock is exhausted.

1шт.

F88308

TUBE - torque (19 ft. hdr.) Replaces F87329 (Before #8366851)

1шт.

F88849

TUBE - torque (19 ft. hdr.) (#8366851 and after)

1шт.

F88590

TUBE - torque (20 ft. hdr.)

1шт.
