Запчасти Case IH 1660 (054) - HEADER AUGER TROUGH, 16 FT., 19 FT., 20 FT. (58) - ATTACHMENTS/HEADERS

1

F13491

COVER - R.H., torque tube (19 ft.)

1шт.

F13489

COVER - R.H., torque tube (16 ft. and 20 ft.)

1шт.

2

F13490

COVER - L.H., torque tube (16 ft.- 19 ft. - 20 ft.)

1шт.

2a

F30036

COVER - end, torque tube (20 ft.)

2шт.

3

F13460

EXTENSION - back sheet, 19 ft. auger trough

1шт.

4

F13459

SCREW

BACK SHEET - (16 ft - 19 ft.)

2шт.

F30029

BACK SHEET - (20 ft.)

2шт.

5

F8286

SHIELD - feed rake, R.H.

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

5шт.

95-4

WASHER,1/4"

- U.S. std. flat 1/4"

5шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

5шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

5шт.

6

F8285

SHIELD - feed rake, L.H.

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

5шт.

95-4

WASHER,1/4"

- U.S. std. flat 1/4"

5шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

5шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

5шт.

7

F13495

SHIELD - feed rake chain

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

2шт.

14-46

BOLT - 1/4" x 3/8" N.F. hex.

13шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

15шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

15шт.

8

NSS

NOT SOLD SEPARAT

ANGLE - header lift

1шт.

9

NSS

NOT SOLD SEPARAT

CLEVIS - "U" Type, header lift

1шт.

10

F13450

CHANNEL - filler

1шт.

11

F13453

FLOOR - auger trough, R.H. (16 ft. - 19 ft.)

1шт.

F30024

FLOOR - auger trough, R.H. (20 ft.)

1шт.

12

F13449

FLOOR - center, auger trough

1шт.

13

F13454

FLOOR - auger trough, L.H. (16 ft. - 19 ft.)

1шт.

F30025

FLOOR - auger trough, L.H. (20 ft.)

1шт.

14

F13472

STRIPPER - ajdustable (R.H. and L.H. for 16 ft., L.H. only for 19 ft.) See Ref. 27

2шт.

F30031

STRIPPER - adjustable (R.H. and L.H. for 20 ft.)

2шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk. (14-for 16 ft., 7 for 19 ft.)

1шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

95-4

WASHER,1/4"

- U.S. std 1/4"

1шт.

25-104

NUT,1/4"-20, G5

1шт.

15

F13471

SCREW

ANGLE - stripper, upper L.H. (16 ft. - 19 ft.)

1шт.

F30030

ANGLE - stripper, upper L.H. (20 ft.)

1шт.

16

F13474

SCREW

ANGLE - stripper, lower L.H. (16 ft. - 19 ft.)

1шт.

F30032

ANGLE - stripper, lower L.H. (20 ft.)

1шт.

17

F9389

REINFORCEMENT - cutter bar, L.H. (5 req. for 16 ft., 6 req. for 19 ft., 7 req. for 20 ft.)

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

1шт.

14-516

BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd

- 5/16" x 1" N.F. hex.

1шт.

92-5

LOCK WASHER,5/16"

1шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

1шт.

18

F10794

HOOK RAIL - auger trough, R.H. and L.H. (16' - 19')

2шт.

25

F13481

SCREW

ANGLE - stripper, lower R.H. (19 ft. header)

1шт.

F10794

HOOK RAIL - auger trough, center (20 ft.)

3шт.

F13457

HOOK RAIL - auger trough, L.H. (20 ft.)

1шт.

19

F8289

HOOK RAIL - feeder spout, L.H.

1шт.

F30037

STIFFENER - Hook rail, for F8288 and F8289 (16 ft. and 20 ft. hdr.)

2шт.

20

F8288

HOOK RAIL - feeder spout, R.H.

1шт.

21

F9388

REINFORCEMENT - cutter bar, R.H. (5 req. for 16 ft., 6 req. for 19 ft., 7 req. for 20 ft.)

1шт.

14-516

BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd

- 5/16" x 1" N.F. hex.

1шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

1шт.

92-5

LOCK WASHER,5/16"

1шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

1шт.

22

F10318

HOOK RAIL - L.H., 19 ft. auger trough

1шт.

23

F10317

HOOK RAIL - R.H., 19 ft. auger trough

1шт.

24

F13455

EXTENSION - 19 ft. auger trough floor

1шт.

25

F13481

SCREW

ANGLE - stripper, lower R.H. (19 ft. header)

1шт.

F13480

SCREW

ANGLE - stripper, lower R.H. (16 ft. header)

1шт.

F30034

ANGLE - stripper, lower R.H. (20 ft. header)

1шт.

26

F13477

SCREW

ANGLE - stripper, upper R.H. (19 ft. header)

1шт.

F13476

SCREW

ANGLE - stripper, upper R. H. (16 ft.)

1шт.

F30033

ANGLE - stripper, upper R. H. (20 ft. header)

1шт.

27

F13478

SCREW

STRIPPER - adjustable, R. H. (19 ft. header) see Ref. 14

1шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk.

9шт.

95-4

WASHER,1/4"

- U.S. std. 1/4"

9шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

9шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.C. hex.

9шт.
