Запчасти Case IH 1660 (052) - 14 FT. HEADER AUGER TROUGH (58) - ATTACHMENTS/HEADERS

1

F13487

COVER - R.H., torque tube

1шт.

2

F13488

COVER - L.H., torque tube

1шт.

3

F13458

BACKSHEET

2шт.

4

F8286

SHIELD - feed rake, R.H.

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

5шт.

95-4

WASHER,1/4"

- U.S. std. flat 1/4"

5шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

5шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

5шт.

5

F8285

SHIELD - feed rake, L.H.

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

5шт.

95-4

WASHER,1/4"

- U.S. std. flat 1/4"

5шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

5шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

5шт.

6

F13495

SHIELD - feed rake chain

1шт.

14-410

SCREW,Hex, 1/4" - 28 x 5/8", Gr 5

BOLT - 1/4" x 5/8" N.F. hex.

2шт.

14-46

BOLT - 1/4" x 3/8" N.F. hex.

13шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

15шт.

25-114

NUT,1/4"-28, G5

- 1/4" N.F. hex.

15шт.

7

F13450

CHANNEL - filler

1шт.

8

F13451

FLOOR - auger trough, R.H.

1шт.

9

F13449

FLOOR - center, auger trough

1шт.

10

F13452

FLOOR - auger trough, L.H.

1шт.

11

F13467

SCREW

STRIPPER - adjustable, R.H. and L.H.

2шт.

111-102

CARRIAGE BOLT,Short NK, 1/4"-20 x 5/8", G2

BOLT - 1/4" x 5/8" rhd. sq. nk.

14шт.

95-4

WASHER,1/4"

- U.S. std. 1/4"

14шт.

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

14шт.

25-104

NUT,1/4"-20, G5

14шт.

12

F13464

ANGLE - stripper, upper L.H.

1шт.

13

F13473

SCREW

ANGLE - stripper, lower L.H.

1шт.

14

F9389

REINFORCEMENT - cutter bar, L.H.

5шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

1шт.

14-516

BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd

- 5/16" x 1" N.F. hex.

6шт.

92-5

LOCK WASHER,5/16"

7шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

7шт.

15

F10794

HOOK RAIL - auger trough, R.H. and L.H.

2шт.

16

F8289

HOOK RAIL - feeder sprout, L.H.

1шт.

17

F9388

REINFORCEMENT - cutter bar, R.H.

5шт.

14-512

BOLT,Hex, 5/16" - 24 x 3/4", Gr 5, Full Thd

1шт.

14-516

BOLT,Hex, 5/16" - 24 x 1", Gr 5, Full Thd

- 5/16" x 1" N.F. hex.

5шт.

92-5

LOCK WASHER,5/16"

6шт.

25-115

NUT,5/16"-24, G5

- 5/16" NF hex

6шт.

18

F8288

HOOK RAIL - feeder spout, R. H.

1шт.

19

F13475

SCREW

ANGLE - stripper, upper R.H.

1шт.

20

F13479

SCREW

ANGLE - stripper, lower R.H.

1шт.
