Запчасти Case IH 1660 (041A) - SICKLE AND CUTTER BAR, 14 FT., S/N 8334601 AND AFTER (58) - ATTACHMENTS/HEADERS

1

F14136

ANGLE - finger wiper (14 ft. pickup header)

2шт.

111-324

CARRIAGE BOLT,Short NK, 3/8"-16 x 7/8", G2

BOLT, CARRIAGE, , and Nut (129-103) Short NK, 3/8"-16 x 7/8", G2

12шт.

2

F13506

SPARE PART

RAIL - cutter bar

1шт.

11-516

BOLT,Short NK, 5/16"-18 x 1", G2

CARRIAGE, Short NK, 5/16"-18 x 1", G2

20шт.

11-512

SCREW,Short Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

4шт.

92-5

LOCK WASHER,5/16"

24шт.

9635082

NUT,5/16" - 18, Gr 5

- 5/16" N.C. hex.

24шт.

3

111-321

SQUARE BOLT,Short Nk, 3/8" - 24 x 1 1/4", Gr 5

BOLT - 3/8" x 1-1/4" N.F. rhd. sq. nk. (Gr. 5) sickle guard

28шт.

111-343

BOLT

- 3/8" x 1" N.F. rhd. sq. nk. (Gr. 5) sickle guard

28шт.

25-116

NUT,Hex, 3/8"-24, G5

- 3/8" N.F. hex., and lockwasher (92-6)

56шт.

4

F13511

CLIP

- sickle hold-down

14шт.

5

F13505

REINFORCEMENT - cutter bar rail

1шт.

6

F3154

GUARD

- sickle

27шт.

F3153

GUARD - sickle, L.H. end

1шт.

7

F84171

GUARD - pickup, grain saving (Special)

1шт.

8

A30455

SPRING

1шт.

9

F92617

KNIFE ASSY

SICKLE - 14 ft. (with 55 - MT944S sections)

1шт.

10

MT944S

KNIFE SECTION

SECTION - under serrated (std.)

55шт.

11

Z1690

RIVET

- (#5 - 1/2 x 9/16" rhd.) sections to bar (1 lb. pkg.)

1шт.

12

F22513

CUTTER BAR

HALF SECTION - smooth (See F59129)

1шт.

13

F13701

PLATE - filler

1шт.

47-418

RIVET - 1/4" x 1-1/8" fl. hd.

2шт.

14

Z1716

RIVET

- (#5 - 1/2 x 1" rhd.) for riveting sections to sickle head (1 lb. pkg.)

1шт.

15

F77330

HEAD

- sickle

1шт.

16

A26629

BEARING

- pitman socket (one each side of head)

2шт.

17

F8360

ADJUSTMENT SCREW,1 5/16" - 18 x 3/4"

- adjusting, pitman

1шт.

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - 1/8" str. (for F77330 head)

1шт.

F92616

SICKLE - 14 ft. (with 55-T13010 sections)

1шт.

T13010

KNIFE SECTION

SECTION - under serrated (chrome plated) Also includes Ref. 11, 12, 13, 14 and 15

1шт.

F96333

SICKLE - 14 ft. (with 55-O14295S sections)

1шт.

O14295S

KNIFE SECTION

SECTION - top serrated (See F59106) Also includes Ref. 11, 12, 13, 14 and 15

1шт.

F59106

KNIFE SECTION

SECTION - top serrated (chrome plated) Special

1шт.

T13009

KNIFE SECTION

SECTION - smoorth (chrome plated) Special

1шт.

F59129

HALF SECTION - smooth (chrome plated) Special

1шт.

T13489

RIVET

- (#5 - 1/2 x 9/16" rhd. plated) chrome sections (1 lb. pkg.)

1шт.
