Запчасти Case IH 1644 (1-20) - PICTORIAL INDEX, OIL COOLER SYSTEM (00) - PICTORIAL INDEX

Схема запчастей Case IH 1644 - (1-20) - PICTORIAL INDEX, OIL COOLER SYSTEM (00) - PICTORIAL INDEX
1
2
6
12
10
11
8
3
5
4
1
9
1

Артикул

Название

Примечание

Количество

1

Reverse Pressure Hose, Figure 6-2

1шт.

2

Reverse Pressure Tube, Figure 6-2

1шт.

3

Housing Drain Upper Hose, Figure 6-2

1шт.

4

Case Drain Tube, Figure 6-2

1шт.

5

Housing Drain Lower Hose, Figure 6-2

1шт.

6

Forward Pressure Upper Hose, Figure 6-2

1шт.

7

Forward Pressure Tube, Figure 6-2

1шт.

8

Forward Pressure Lower Hose, Figure 6-2

1шт.

9

Foot-N-Inch Hose, Figure 6-10

1шт.

10

Foot-N-Inch Lower Tube, Figure 6-10

1шт.

11

Foot-N-Inch Center Tube, Figure 6-10

1шт.

12

Foot-N-Inch Upper Tube, Figure 6-10

1шт.

Выбрано товаров: 12
