Запчасти Case IH 1644 (4-24) - FEEDER REVERSER HARNESS (06) - ELECTRICAL

Схема запчастей Case IH 1644 - (4-24) - FEEDER REVERSER HARNESS (06) - ELECTRICAL
14
16
13
2
15
7
6
12
3
1
11
9
10
17
5
8

Артикул

Название

Примечание

Количество

1

103898A1

CABLE

HARNESS feeder reverser

1шт.

2

453453C1

SWITCH

push button feeder reverser

1шт.

3

245927C91

STARTING MOTOR

ASSEMBLY feeder reverser, parts list Figure 4-46

1шт.

3

245927C93R

REMAN-STARTER

REMANUFACTURED STARTING MOTOR

1шт.

3

245927C93C

CORE-STARTER

Return Number, STARTING MOTOR

1шт.

5

261-1478

SELF-TAP SCREW,Cross Pan Hd, 1/4" x 1/2"

self-tapping, pan Phillips, 1/4 NC x 1/2 inch

2шт.

6

103843A1

CABLE

battery positive

1шт.

7

515-23254

CLAMP,1", Insul, 3/8" Bolt

P-type

10шт.

8

702093C1

CABLE TIE

CABLE STRAP

1шт.

9

413-636

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

3шт.

10

231-5146

FLANGE NUT,3/8"-16

3шт.

178149A1

SOLENOID SWITCH

KIT with barrier and cover

1шт.

11

178148A1

COVER

solenoid switch starting

1шт.

12

183038A1

SOLENOID

SWITCH with barrier, Replaces A39079

1шт.

13

225-14210

NUT,#10-32

1шт.

14

425-105

NUT,5/16"-18, G5

2шт.

15

492-11010

LOCK WASHER,#10

1шт.

16

492-11031

LOCK WASHER,5/16"

2шт.

17

L18337

CABLE TIE,9.95"-12.1" lg

CABLE STRAP tie nylon, 19 x 15.44 inch

2шт.

Выбрано товаров: 19
