Запчасти Case IH 1640 (4-30) - GRAIN TANK HARNESS (06) - ELECTRICAL

1

245243C3

HARNESS

- grain tank

1шт.

2

702093C1

CABLE TIE

STRAP - cable retaining

1шт.

3

91436C3

SWITCH

- unloader in

1шт.

4

440-11012

SCREW,Cross Pan Hd, #10-24 x 3/4"

- machine, pan head Phillips, No. 10 NC x 3/4 inch

2шт.

5

225-14110

NUT,#10-24

2шт.

6

493-81001

LOCK WASHER,Ext-Int Tooth, #10

WASHER - internal-external lock, No. 10

2шт.

7

1338022C1

SUPPORT

BRACKET - unloader in switch

1шт.

8

68530C1

BOLT,Hex Serr, 1/4" - 20 x 3/4"

- flanged hex lock, 1/4 NC x 3/4 inch

2шт.

9

938016R1

FLANGE NUT,Flg, USR, 1/4"-20

- flanged hex lock, 1/4 inch NC

2шт.

11

REF

INSTRUCTION

LAMP ASSEMBLY - warning, right front (See Figure 4-44)

1шт.

12

REF

INSTRUCTION

LAMP ASSEMBLY - grain tank (See Page 4-41)

1шт.

19

299401C1

CLAMP,5/16", Insul, 1/4" Bolt

CLIP - harness

12шт.

20

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd

12шт.

21

492-11031

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

12шт.

22

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC

12шт.

23

537641R2

SWITCH ASSY

SWITCH - unloader out

1шт.

24

490-1108

SCREW,Cross Pan Hd, #10-32 x 1/2"

- machine, pan head Phillips, No. 10 NF x 1/2 inch

2шт.

25

115999

NUT,#10-32

- hex machine, No. 10 NF

2шт.

27

1338003C1

BRACKET

SUPPORT - unloader limit switch out

1шт.

28

1338004C1

BRACKET

BAR - unloader limit switch out

1шт.

30

198823C1

GROMMET,9.53mm ID x 41.1mm OD x 26.9mm Thk

- grain bin, 3/8 x 1-5/8 x 1-1/16 inch

1шт.

31

195803C1

GROMMET

- grain tank harness, upper

2шт.

41

91828C1

HARNESS

ASSEMBLY - unloader light

1шт.

42

702093C1

CABLE TIE

STRAP - cable- retaining, unloader light harness

1шт.

43

299401C1

CLAMP,5/16", Insul, 1/4" Bolt

CLIP - harness, unloader light

3шт.

44

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd, Unloader light harness

3шт.

45

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, , Unloader light harness 5/16"

3шт.

46

425-105

NUT,5/16"-18, G5

- hex, 5/16 inch NC, Unloader light harness

3шт.

47

REF

INSTRUCTION

LAMP ASSEMBLY - unloader (See Page 4-41), harness

1шт.

26

493-81000

LOCK WASHER,Ext-Int Tooth, #10

WASHER, LOCK, (3/16") Ext-Int Tooth, #10

2шт.
