Запчасти Case IH 1620 (9-218) - SEAT ASSEMBLY, BOSTROM (10) - CAB & AIR CONDITIONING

Схема запчастей Case IH 1620 - (9-218) - SEAT ASSEMBLY, BOSTROM (10) - CAB & AIR CONDITIONING
1
5
6
3
2
4

Артикул

Название

Примечание

Количество

91789C91

SEAT

ASSEMBLY - operators, Includes: seat complete suspension kit, Ref. 1 - 6, seat top kit and miscellaneous parts kit in this figure and parts in Figures 9-216 and 9-220

1шт.

1954465C1

KIT

SUSPENSION KIT - seat complete, Includes: Ref. 1 - 6

1шт.

1

NSS

NOT SOLD SEPARAT

SUSPENSION - seat

1шт.

2

NSS

NOT SOLD SEPARAT

COVER - suspension

1шт.

3

NSS

NOT SOLD SEPARAT

STOP - forward

1шт.

4

NSS

NOT SOLD SEPARAT

SCREW - stop retaining, M5 x 10 mm

1шт.

5

NSS

NOT SOLD SEPARAT

WASHER - lock, 5 mm

1шт.

6

NSS

NOT SOLD SEPARAT

SLIDER - seat

2шт.

Part of Seat Top Kit P/N 1954469C1

1шт.

Part of Miscellaneous Parts Kit P/N 1954471C1

1шт.

1954469C1

KIT

TOP KIT - seat, Includes: Ref. 6 in this figure and parts in Figure 9-216

1шт.

1954471C1

KIT

PARTS KIT - miscellaneous, Includes: Ref. 6 in this figure and parts in Figures 9-216 and 220

1шт.

Выбрано товаров: 12
