Запчасти Case IH 1480 (24-09) - CLEANING FAN AND DRIVE, FAN SHIELDS (15) - CLEANING

1

182824C3

GUARD ASSY.

SHIELD ASSY, LH fan drive

1шт.

2

182846C3

SUPPORT

SHIELD ASSY, RH fan drive

1шт.

3

561277R1

SPACER,5/8" Tube x 1/2"

.407 x .625 x .438, for LH and RH fan shield

4шт.

180124

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

3/8 x 1-1/4 type 5

1шт.

482256R1

BEARING LOCK NUT,Flg, USR, 3/8"-16

3/8 flange lock

1шт.

21403R1

WASHER

.406 x 1.000 x .120

1шт.

4

181304C1

SUPPORT

latch retaining, Serial Range: -15180

1шт.

5

181496C1

SHIELD

latch

2шт.

436734

SCREW,Slotted Pan Hd, #10-24 x 3/4"

n. 10 x 3/4 znp p/hds mach

1шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 C-Z flange lock

1шт.

6

188103C1

BRACKET

YOKE, hook retaining, Serial Range: -15180

2шт.

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

5/16 x 1/2 slt-truss-hd

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

7

764071C1

BRACKET

HOOK, fan shield latch bracket

2шт.

436734

SCREW,Slotted Pan Hd, #10-24 x 3/4"

no. 10 x 3/4 znp p/hds mach

1шт.

174097C1

FLANGE NUT,Flg, USR, #10-24

10-24 C-Z flange lock

1шт.

8

494307C1

LATCH

HOOK, fan shield hold-down latch

2шт.

648002

KNIFE

1/8" x 3/4"

1шт.

24812R1

HEADED PIN,1/4" x 2"

PIN, HEADED, 1/4" x 2"

1шт.

9

182858C2

SUPPORT

fan shield rear LH

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

10

182859C2

SUPPORT

fan shield rear RH

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

11

82860C1

ANGLE, front LH shield

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

12

182861C1

ANGLE

front RH shield

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

13

182864C1

SHIELD

left front

1шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

14

182867C1

SHIELD

right front

1шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

15

182812C1

ROD

fan shield

1шт.

18481R1

COTTER PIN,3/16" x 1"

PIN, SPLIT (COTTER), 3/16" x 1"

1шт.

16

182823C1

SUPPORT

bottom screen rear retainer

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

17

182817C2

GUARD ASSY.

SHIELD ASSY, lower fan LH

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

18

182817C2

GUARD ASSY.

SHIELD ASSY, lower fan RH

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

19

182874C1

SUPPORT

fan bearing LH

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

20

182875C1

SUPPORT

fan bearing RH

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

5/16 x 1 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

21

182873C1

SUPPORT

ASSY, axle to auger bed seal

2шт.

22

182809C2

GUARD

SHIELD, intake lower rear

2шт.

23

182805C1

SHIELD

intake upper rear LH

1шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

24

182806C1

SHIELD

intake upper rear RH

1шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4 type 5

1шт.

938017R1

FLANGE NUT,Flg, USR, 5/16"-18

5/16 flange lock

1шт.

25

1302723C1

HOOK

S-HOOK, inlet shield, Serial Range: -15181

2шт.
