Запчасти Case IH 1480 (01-01) - PARTS ACCESSORIES, PARTS ACCESSORIES AND PACKAGES Accessories & Attachments / Miscellaneous

71151C91

HEATER

engine block

1шт.

549978C91

BRACKET

fire extinguisher, refer to group 13 under fire extinguisher

1шт.

549975C91

FIRE EXTINGUISHER

EXTINGUISHER, fire, refer to group 13 under fire extinguisher

1шт.

183820C2

SIEVE, shoe 1/10 round hole

1шт.

186821C2

GRAIN SIEVE

SIEVE, shoe 7/32 round hole

1шт.

186822C2

GRAIN SIEVE

SIEVE, shoe 3/8 round hole

1шт.

186823C2

GRAIN SIEVE

SIEVE, shoe 1/2 round hole

1шт.

1302233C2

GRAIN SIEVE

SIEVE, 1-5/8 CLDSZ slat shoe, refer to group 23 under shoe and shoe sieve

1шт.

180771C91

KIT

DIVIDER, grain pan side hill, refer to group 23 under grain pan side hill dividers

1шт.

121897C92

FILTER

COOLANT FILTER, conditioner, refer to group 6 under coolant filter, conditioner

1шт.

1300098C92

SHIELD

oscillating steering, grain and corn, refer to group 14 under steering axle shield, Serial Range: -14000

1шт.

180121C91

PACKAGE

feeder front LH deflector, not for use w/810 draper header

1шт.

180122C91

PACKAGE

feeder front LH deflector, for use w/810 draper header

1шт.

1300464C91

PACKAGE

feeder pivot strippers

1шт.

1319277C91

PACKAGE

alfalfa, refer to group 23 under auger bed, shoe and shoe sieve

1шт.

1319979C91

KIT

PACKAGE, clean grain, refer to group 25 under grain auger trough, note auger must also be ordered for use with this package

1шт.

1324002C91

KIT

PACKAGE, fan housing, refer to group 24 under cleaning fan and shields

1шт.

1319093C2

GRAIN SIEVE

SIEVE, Peterson chaffer, refer to group 23 under chaffer sieve

1шт.

1320922C2

BLADE

rock trap serrated blade extension, refer to group 23 under rock trap

1шт.

1319405C1

GRATE

ASSY, smooth, refer to group 21 under concave and control

3шт.

1300496C91

STRIPPER PACKAGE

PACKAGE, feeder clutch jackshaft drive friction slip, refer to group 33 under feeder jackshaft drive, Serial Range: -14000

1шт.

1302193C92

RUBBER FLIGHT

FLIGHT ASSY, grain elevator, refer to group 25 under grain elevator, Start Serial: 14001

1шт.

188188C1

SPROCKET ASSY.

SPROCKET, grain elevator spout driven, fast speed, 27 T

1шт.

188189C1

SPROCKET ASSY.

SPROCKET, grain elevator spout driven, slow speed, 33 T, refer to group 25 under elevator drive

1шт.

1300666C91

KIT

PACKAGE, auger bed grain spreader, refer to group 23 under auger bed

1шт.

1300673C91

PACKAGE

small wire concave, refer to group 21 under concave and control

1шт.

118154C91

ACCESSORIES

CABLE, head phone connecting jack, refer to group 13 under radio

1шт.

153299C91

CONVEYOR

FLIGHT ASSY, tailings elevator, steel, refer to group 25 under tailings elevator, Serial Range: -14000

1шт.

1303124C92

RUBBER FLIGHT

FLIGHT ASSY, tailings elevator, steel, refer to group 25 under tailings elevator, Start Serial: 14001

1шт.

183303C91

STEEL FLIGHT

FLIGHT ASSY, grain elevator, steel, refer to group 25 under grain elevator, Serial Range: -14000

1шт.

111640C92

RADIO

AM with fader control

1шт.

111641C92

RADIO

AM/FM monaural

1шт.

111642C92

RADIO

AM/FM multiplex with 8 track tape player

1шт.

142947C93

RADIO

AM/FM/CB multiplex

1шт.

146558C91

RADIO

AM/FM push button with cassette tape player

1шт.

143186C92

RADIO

PACKAGE, radio mounting, refer to group 13 under radio

1шт.

245344C91

RADIO

AM 15 watts per channel

1шт.

245160C91

RADIO

AM-FM stereo 15 watts per channel

1шт.

91667C1

PACKAGE

radio installation, refer to group 13 under radio 15 watt/channel

1шт.

1300716C91

CHANNEL

PACKAGE ASSY, large wire concave, refer to group 21 under concave and control, sets of 6

1шт.

1319274C91

FENDER

PACKAGE ASSY, shoe return w/increased slope, refer to group 23 under shoe sieve, Serial Range: -34000

1шт.

1324031C1

PACKAGE

grain rotor separator angle bar support, refer to group 21 under rotor for grain and corn

1шт.

1315475C91

PACKAGE

KIT, reel pump service, refer to group 10 under reel drive pump for ross pumps

1шт.

91906C91

KIT

PACKAGE, alternator-generator completing, package does not include atl-gen-refer to group 8 under alternator-generator

1шт.

1323569C92

FEEDER

REVERSER, feeder retrofit package, for combines without rocktrap, Start Serial: 54001

1шт.

1323570C92

FEEDER

REVERSER, feeder retrofit package, for combines with rocktrap, refer to group 13 under feeder reverser, Start Serial: 54001

1шт.

1957364C1

LATCH

PACKAGE, rocktrap door latch retrofit, refer to group 33 under rocktrap

1шт.
