Артикул
Название
Примечание
Количество
1
1324450C1
SLEEVE
cordura hose, 3.29 ID x 36 in. long
4шт.
2
1324451C1
PROTECTIVE SLEEVE,40.4 mm ID x 914.50 mm
SLEEVE, 40.40 mm ID x 914.50 mm, Cordura Hose
2шт.
3
9410283
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
3/4 C-Z hyd fld 90D swivel
10шт.
4
1324452C1
HOSE
drive, 54.5 long
4шт.
5
1324453C1
HOSE
drive, 86.0 long
2шт.
6
1324466C91
VALVE
ASSY, equa-trac
1шт.
7
394955R1
HYD CONNECTOR,9/16"-18, 37 Degree x 7/16"-20, O-Ring
CONNECTOR, C-Z hyd fld 3/8 to 1/4 sht
1шт.
8
369751R1
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
4-1, 90 Duro, .351" ID x .072" Thk, 1/4 OD tube, class 6
2шт.
9
9410306
TEE,37 Degree, 9/16"-1 x 9/16"-18, Fem Sw Br
3/8 C-Z hyd fld tube swivel
1шт.
10
9410200
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
CONNECTOR, 1/4 C-Z hyd fld short swivel
1шт.
11
9410332
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
3/8 C-Z hyd fld tube swivel
1шт.
12
9410205
HYD CONNECTOR,1 1/16"-12, 37 Degree x 1 1/16"-12, O-Ring
CONNECTOR, 3/4 C-Z hyd fld short swivel
4шт.
13
368269R1
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
OD tube class 6
6шт.
14
9410231
HYD CONNECTOR,1 1/16"-12, 37 Degree x 1 1/16"-12, Pipe
CONNECTOR, 3/4 C-Z hyd fld long swivel
2шт.
15
28135R1
CLAMP
.938 dia znp coated med clo
2шт.
24875R1
BOLT,Hex, 5/8" - 11 x 2", Gr 8
2шт.
25949R1
JAM NUT,Jam, 5/8"-11, G8
5/8 PHC jam type 8
2шт.
16
935036R91
ELBOW
C-Z hyd fld adj 1/2 to 3/8 90D
2шт.
18
1324476C2
ELBOW
high pressure swivel
4шт.
19
368269R1
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
3/4 OD tube class 6
4шт.
20
1315517C1
HOSE
ASSY, pressure
2шт.
21
1315518C1
HYDRAULIC HOSE,9.52 mm ID x 1780.00 mm
- Drain 9.52 mm ID x 1780.00 mm
1шт.
22
1315519C1
HOSE
ASSY, charge pressure
1шт.
23
9410205
HYD CONNECTOR,1 1/16"-12, 37 Degree x 1 1/16"-12, O-Ring
CONNECTOR, 3/4 C-Z hyd fld short swivel
2шт.
24
368269R1
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
3/4 OD tube class 6
2шт.
25
9410278
ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, 37 Degree Fem Sw
1/4 C-Z hyd fld 90D swivel
1шт.
26
138961C1
HOSE
ASSY, valve pressure, 36 in. long
1шт.
27
9410200
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
CONNECTOR, 1/4 C-Z hyd fld short swivel
1шт.
28
369751R1
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
4-1, 90 Duro, .351" ID x .072" Thk, 1/4 OD tube, class 6
1шт.
29
1315504C1
HOSE
valve drain
1шт.
30
244713R1
HOSE CLAMP,#4, 0.25/0.62 Type M Worm
CLAMP, drain hose
1шт.
31
995218R1
CLAMP
return hose
2шт.
32
HOSE, return, use 7 in. of 3/4 hyd hose from 25 ft roll marked 180720C1
1шт.
33
1304931C1
HOSE,19.05mm ID x 762mm L
ASSY, valve pressure, 30 in. long
2шт.
34
1301715C1
TUBE
ASSY, hydro drive forward, upper pressure
1шт.
35
1301714C1
TUBE
ASSY, hydro drive reverse, upper pressure
1шт.
36
(Not used this application)
1шт.
37
1315489C91
VALVE
ASSY, drive selector, refer to drive selector valve
1шт.
38
196709C1
TEE
return hose
1шт.
39
1324472C1
BRACKET
hose support
2шт.
1324474C1
PLATE
bracket
2шт.
25236R1
BOLT,Hex, 5/16" - 18 x 3", Gr 8
5/16 x 3 PHC type 8
2шт.
40
9411128
TEE,7/16"-20, 37 Degree x 7/16"-20, O-Ring Run
1/4 C-Z hyd fld tube adj, use w/2 speed motor
1шт.
41
9410974
ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, O-Ring
1/4 C-Z hyd fld adj 90D, use w/1 speed motor
1шт.
Выбрано товаров: 45
