Артикул
Название
Примечание
Количество
1
613524C91
SPHERICAL BEARING,44.44mm ID x 71.44mm OD x 38.89mm W
BEARING, spherical radial
4шт.
2
1310550C1
SUPPORT ASSY.
SUPPORT ASSY, LH box
1шт.
2
1310549C1
SUPPORT ASSY.
SUPPORT ASSY, RH box
1шт.
469805R1
BOLT,Hex, 5/8" - 11 x 2", Gr 8
5/8 x 2 type 8
1шт.
25528R1
NUT,5/8"-11, G8
5/8 PHC type 8
1шт.
3
1310551C1
BOLT,Hex, 1 5/8" - 12 x 2.73"
BOLT, center ported pivot
4шт.
4
9403299
LOCK NUT,Blkhd, 1 5/8"-12
NUT, ported pivot bolt
4шт.
5
1310552C1
ELBOW
90 deg hi-pressure swivel
4шт.
368269R1
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
3/4 OD tube class 6
1шт.
6
1310554C91
CASE
ASSY, planitary gear, includes ref no. 7
2шт.
24873R1
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 8
1шт.
25976R1
WASHER,21/32" x 1 5/16" x .150", HDN
.656 x 1.312 x .150 PHC HDN
1шт.
7
1310563C1
STUD,5/8" - 18 x 2.15"
BOLT, steering tire mounting
18шт.
25676R1
NUT,5/8"-18, G8
5/8-NF PHC type 8
1шт.
25556R1
WASHER,21/32" x 1 1/2" x .188", HDN
.656 x 1.500 x .188 PHC HDN
1шт.
8
1310555C1
GASKET
hyd motor
2шт.
9
1310556C91
MOTOR, ELECTRIC
MOTOR ASSY, fixed axial position
2шт.
427566
BOLT,Hex, 1/2"-13 x 1 1/2", G8, Full Thd
1/2 x 1-1/2 type 8
1шт.
25710R1
WASHER
.531 x 1.062 x .134 HDN
1шт.
10
9410979
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, O-Ring
3/4 C-Z hyd adj 90 deg
8шт.
368269R1
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
3/4 OD tube class 6
1шт.
11
9410977
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
1/2 C-Z hyd adj 90 deg
2шт.
12
1310558C1
TUBE
ASSY, motor lower LH
1шт.
12
1310581C1
TUBE
ASSY, motor lower RH
1шт.
13
1310559C1
TUBE
ASSY, motor upper LH
1шт.
13
1310582C1
TUBE
ASSY, motor upper RH
1шт.
14
1310560C1
THRUST WASHER
thrust washer
2шт.
15
890477C1
WASHER
WASHER
4шт.
16
1310562C1
THRUST WASHER
thrust
2шт.
17
EXTENSION, axle, refer to this group under axle power guide wheel
1шт.
18
299565C1
CLAMP
.688 dia. znp coated
1шт.
1272263C1
KIT
fixed axial motor, consists of o-ring (NSS), retaining ring (NSS), retaining ring (NSS), shaft seal (NSS)
1шт.
1319387C1
SEAL KIT
gear case seal, consists of o-ring (NSS), retaining ring (NSS), spindle seal (NSS), o-ring (NSS), (2) seal (NSS), roll pin (NSS)
1шт.
Выбрано товаров: 34
