Артикул
Название
Примечание
Количество
1
189418C1
BLOCK
jackshaft bearing, Serial Range: -20976
1шт.
1
181369C1
BEARING HOUSING
BLOCK, jackshaft bearing, Start Serial: 20977
1шт.
88530
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
BOLT, 1/2 x 1-3/4 crg type 5
1шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
1шт.
120384
WASHER,1/2"
LOCK, 1/2"
1шт.
25555R1
WASHER,17/32" x 1 1/4" x .188", HDN
.531 x 1.250 x .188 PHC hdn
1шт.
2
109461
LUBE NIPPLE,1/8"-27 x .66 lg
NIPPLE, LUBE, 1/8"-27 x .66 lg
1шт.
3
61991R91
BREATHER,1/8"-27 NPT, Short, w/washer
VALVE ASSY, bearing block breather
1шт.
4
191452C2
PULLEY
jackshaft driven, 14.75 in. OD
1шт.
5
189419C1
FLANGE,2.4788" ID x 4.5" OD x 1.3"
HUB, rear bearing
1шт.
20617R1
BOLT,Hex, 5/16" - 18 x 1", Gr 8
5/16 x 1 type 8
1шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
1шт.
6
156229C1
SHIM,76.45mm ID x 111.25mm OD x 0.13mm Thk
Bearing Hub 0.005" Thk
1шт.
6
188183C1
SHIM,0.007" Thk
Bearing Hub 0.007" Thk
1шт.
6
188184C1
SHIM,0.010" Thk
Bearing Hub 0.010" Thk
1шт.
8
61802C91
ROLLER BEARING,38mm ID x 17mm Thk
BEARING, jackshaft cone
2шт.
9
61801C1
BEARING CUP,63mm OD x 13.5mm W
BEARING, jackshaft cup
2шт.
10
188931C1
OIL SEAL,47.63mm ID x 63.7mm OD x 8.41mm Thk
Jackshaft Bearing Hub Front, With Shoulder 1.875" ID x 2.503" OD x .62, Start Serial: 20083
1шт.
10
188931C1
OIL SEAL,47.63mm ID x 63.7mm OD x 8.41mm Thk
Jackshaft Bearing Hub Front, With Shoulder, Also required bushing, 188930C1 1.875" ID x 2.503" OD x .62, Serial Range: -20082
1шт.
11
384386R91
OIL SEAL,42.7mm ID x 63.7mm OD x 8.33mm Thk
Jackshaft Bearing Hub Rear 1.752" ID x 2.503" OD x .689
1шт.
12
1308505C1
SHAFT
separator drive, replaces shaft 191565C2 by also furnishing two nuts 9413986 and two washers 25847R1
1шт.
9413986
LOCK NUT,1"-8, GC
NUT, 1 PHC P/T lock type 8
1шт.
25847R1
WASHER
1.062 x 2.000 x .209 hdn
1шт.
14
188930C1
RING,38.05mm ID x 57.15mm OD x 27mm L
BUSHING, jackshaft front, Start Serial: 20083
1шт.
14
188930C1
RING,38.05mm ID x 57.15mm OD x 27mm L
BUSHING, jackshaft front, also required seal 188931C1, Serial Range: -20082
1шт.
15
162678C1
WASHER,1 1/2" ID x 2" OD x .060" Thk
Jackshaft, Hard, 5 or as required 1 1/2" ID x 2" OD x .060" Thk
1шт.
16
160191C2
WASHER
jackshaft 1.5 x 2.0 x .187 hard, not used with bushing 188930C1 at this location only, Serial Range: -20082
1шт.
Выбрано товаров: 29
